Sku: CHO012

Chorus Line 16

Regular price
$2,992.00
Regular price
Sale price
$2,992.00
Shipping calculated at checkout.
Vendor: Elation Professional

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Description

Caret Down

The Chorus Line 16's are great - they allow tilt adjustment and feature really bright LED's and zoom.  They're equally at home lighting a backdrop or providing great beam-y FX behind a stage, or even backlight!

From the Manufacturer:

CHORUS LINE 16™ is a 16 pixel bar wash luminaire featuring 40W 4-in-1 RGBW LEDs, motorized 4° to 40° zoom and 220° tilt movement, full pixel control, 2,700K - 7,000K adjustable linear color temperature, 64 color presets and 14 unique color macros, electronic strobe and 16-bit variable dimming curve modes, adjustable LED refresh rate frequency and gamma brightness for flicker free operation for TV and FILM, DMX, RDM, Kling-NET, and Art-NET protocol support, DMX, RJ45 ethernet, and Locking Power Cable in/out connections, 4 button LCD control panel display, dual quick-lock omega bracket rigging, and a multi-voltage universal auto switching power supply (100-240v).



In the Box:

  • (1) Chorus Line 16
  • (2) Omega Brackets
  • (1) Locking Power Cable

Features:

  • Light Source: 16x 40W RGBW LEDs
  • Color Temperature: 2,700K - 7,000K
  • Beam Angle: Motorized 4° to 40° Zoom
  • Dimming: 16-bit Variable Dimming Curve Modes
  • Refresh Rate: Adjustable (900-25,000 Hz)
  • Strobe: Variable
  • Color: RGBW
  • Effects: 220° Tilt, Individual Pixel Control
  • Control Protocol: DMX, RDM, Kling-Net, Art-Net
  • Operating Modes: DMX, Manual
  • IP Grade: IP30



Tech Specs

Optics:

Light Source Type: RGBW LED

Light Source Wattage: 16x 40w

Minimum Beam Angle: 4.0°

Maximum Beam Angle: 40.0°

Control

DMX Channel Modes: 16 / 18 / 78

DMX 3-Pin Connectors?: No

DMX 5-Pin Connectors?: Yes

Physical:

Length: 42.05 in

Width: 7.44 in

Height: 11.46 in

Weight: 47 lb

Electrical

Voltage Range: 100 - 240 VAC 50/60Hz

Maximum Wattage: 739w

Power Cable Connector - Fixture Side: PowerCON

Main Power Connector on Included Cable: Edison
