Studiolive 16R

The Studiolive 16R is a 16-channel racked digital audio console.

From the Manufacturer

The StudioLive® 16R digital mixer is four audio tools in a single rackspace. Use it as a standalone digital mixer with UC Surface remote mixing software. Pair it with your StudioLive Series III console mixer to use as a stage box or integrated monitor mixer. Connect it with EarMix 16M monitor mixers for the ultimate personal monitor system. Plug it into your studio computer, and you have a continuously bidirectional, 36-channel (18x18) USB audio interface with modeled vintage dynamics and EQ plug-ins on every input and bus. Whether used standalone or as part of a complete audio system, no other rackmount digital mixer is as flexible or as powerful.

Inside the StudioLive 16R, the single-core PreSonus® FLEX DSP Engine powers 18 mixing channels, 10 mix buses, and 130 simultaneous processors, including 2 stereo effects and Fat Channel plug-in models on every input channel and mix bus. This is a true 16-channel digital mixer that can comfortably fit in any size rig. Simply connect it to a standard wireless router and control every mix parameter from your iPad®, Android™ tablet, or Windows® Touch computer using UC Surface. UC Surface was designed to make mixing on a touch screen as intuitive as mixing on faders.

An integrated 36-channel (18x18) audio interface lets you record with digitally recallable analog preamps and a complete rack of vintage EQ and dynamics processors for every channel and bus. Modeled after classic analog studio designs, these compressor and EQ plug-ins load both natively on the StudioLive 16R and inside Studio One®, providing the ultimate mixing and recording flexibility.

Features

• Powered by the new single-core PreSonus® FLEX DSP Engine to provide the most processing of any digital mixer in its class

• 18 input-channel digital rack mixer with 16 digitally controlled XMAX mic/line inputs, 2 FLEX FX returns, 10 mix buses, 6 FlexMixes (Aux, Subgroup, Matrix), 2 dedicated FLEX FX buses, Stereo Main bus

• 130 simultaneous processors: HPF, Gate/Expander, Compressor with Fat Channel plug-in models, 4-band/6-band parametric EQ with Fat Channel plug-in models, Limiter

• 31-band graphic EQ

• 4 FLEX FX slots featuring legendary classic reverb emulations and delays

• State Space Modeled Fat Channel compressor and EQ plug-ins available on every input channel and output bus

• 6 DCAs to control groups of channels

• 36-channel (18x18) recording over USB

• Onboard stereo SD recorder with true Virtual Soundcheck mode

• AVB networking onboard (64x64) to connect with other mixers, NSB-series stage boxes, EarMix 16M personal monitor mixers, and more

• Monitor Mix and Stage Box modes for use with StudioLive® Series III console mixers

• Pair with EarMix 16M personal monitor mixers for the ultimate personal monitor system

• Remote control every mix function from your computer, iPad®, or Android™ tablet with UC Surface (included)

• Put your musicians' monitor mix under their fingers with QMix®-UC (included) for iOS® or Android

• Capture® 3.0 multitrack software included

• Advanced Studio One® integration (Studio One Artist Included)

• Ableton® Live Lite included
