OUTERBOT WASH 340

The Mega-Lite Outerbot Wash 340 combines three lighting elements for one unique fixture, to excel in any indoor or outdoor application.

From the Manufacturer:

The Outerbot Wash 340 is equipped with three lighting elements. First is the pixel wash that can zoom creating a multi‑color wash effect. The second element is a single point multibeam effect, and the third is an RGB Halo. Combining these elements creates a unique tool for your lighting arsenal. This unit is IP65‑rated, making it suitable for any of your outdoor needs.

Features:

• Pixel Wash: The seven outer 40W RGBW LEDs allow for individual pixel control with 16‑bit dimming and a 7°‑33° zoom range. This fixture can create a slight beam or a smooth wash and it also features multiple wash presets for strobing, pixel control, and has 64 built‑in macros.
• Single Point Multibeam Effect: Equipped with a center 60W RGBW LED that can produce a bright, powerful, and even projection. This fixture creates multi‑colored beams of light that produce an explosion of colors in a Moonflower effect that transforms any room. This effect can be further enhanced using its bi‑directional and speed‑control prism.
• RGB Halo: This unit offers an eye‑candy Halo ring with 68 RGB SMD LEDs. It has a variety of hues and highly saturated colors with its 33‑presets and an additional 17 macros, making this feature easy to control.
• IP Rated: This unit is IP65‑rated, adding a level of dust and water protection. This Ingress Protection rating certifies the unit suitable for multiple applications such as outdoor, wet, and/or dusty settings.

Specifications:

• IP Rating꞉ IP65
• Housing꞉ Die cast aluminum
• Power connection꞉ Seetronics SACX3FX IP 65 Panel mount
• Signal connection꞉ 5 Pin XLR In and out & Artnet RJ45 in & out
• Pan movement꞉ 540° (16 Bit, 3 phase stepper motor)
• Tilt movement꞉ 220° (16 Bit, 3 phase stepper motor)
• Zoom angle꞉ 7° Beam angle to 33° Field angle (16 Bit)
• Fuse꞉ Panel mount fuse (5x20mm T6.5A250V)
• Fastening system꞉ Quick release clamp mount, bi directional
• Power supply꞉ Electronic 100-240V AC 50/60
• Power consumption꞉ 2.86 Amps / 338 Watts @120V
• Power link꞉ Max 6 units at 110V & 12 units at 220V

Outer LED

• Light source꞉ Seven 40W RGBW LEDs (16 Bit dimming)
• Color temperature white꞉ 8436K (White Emitter Only)
• CRI (Warm white)꞉ 73
• Segments꞉ 7
• Lumen output꞉ 5654lm (Narrow) & 3546lm (Wide) O

Center LED

• Light source꞉ 60W RGBW LED
• Color temperature white꞉ 8380K
• Single point multibeam prism꞉ Bi-directional, speed control

RGB Halo

• Light source꞉ 68 RGB SMD LED

Control Systems

• Control protocols꞉ DMX 512, Artnet, SACN
• RDM꞉ Yes
• Channel modes꞉ 6 Modes of operation Mode 1꞉ 25 Channel mode Mode 2꞉ 27 Channel mode Mode 3꞉ 30 Channel mode Mode 4꞉ 31 Channel mode Mode 5꞉ 37 Channel mode Mode 6꞉ 52 Channel mode
• Display꞉ Auto Flip display

Size and Weight:

• Fixture Size: 16.5” X 14.5” X 19.12” (41.91 cm X 36.83 cm X 48.56cm)
• Fixture Weight: 56 lb (25.40 kg)
• Packaged Size: 21” X 18.5” X 23.5” (53.34 cm X 46.99 cm X 59.69cm)
• Packaged Weight: 57.5 lb (26.08 kg)
