Sku: OVATIONFD105WW

Ovation FD105WW

$1,000.00
$1,000.00
Shipping calculated at checkout.
Vendor: Chauvet Professional

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Description

Caret Down

With the Ovation FD-105WW, you can get the benefits of LED lighting without having to make large investments in dimming systems.

This LED Fresnel wash employs data and power sensors, allowing it to operate on both dimming and constant power systems. With a large 14° to 63° zoom range and a stunningly soft, warm white wash with a high CRI, it's an excellent LED alternative for old incandescent 6" Fresnels.

From the Manufacturer:

Ovation FD-105WW is a LED Fresnel wash utilizing data and power sensors that make it possible to run on both dimming power systems and constant power rigs. A massive zoom range of 8° to 63° and a beautifully soft, warm white wash with high CRI make it a worthy LED replacement for aging incandescent six-inch Fresnels. Enjoy the benefits of LED lighting without being held back by previous investments made in major dimming systems.

At a glance

  • 6“ warm white LED Fresnel with class leading output

  • Soft and even field of light

  • Works perfectly on conventional dimmers or constant power with DMX

  • Auto-senses power/data and responds appropriately

  • Superior low end dimming whether using dimmers or constant power

  • Perfect fixture for the retrofit market, utilizes existing dimming infrastructure flawlessly

  • 16-bit dimming resolution (DMX mode) for smooth fades

  • Flat, even field of light, with manual zoom (8-63 deg)

  • Virtually silent operation for use in any situation

In the Box:

  • (1) Ovation FD-105WW
  • (1) Neutrik® powerCON® power cord
  • (1) Gel frame (6.25 in/159 mm accessories)

     Features:

    • Light Source:  1 LEDs (WW) 80 W, (2 A)
    • Color Temperature:  3197 K
    • CRI: 91
    • Beam Angle:  8° to 51°
    • Dimming: Electronic
    • Strobe: 0 to 25 Hz
    • Color: Warm White
    • Control Protocol: DMX, RDM, Dimmer
    • Operating Modes:  3 personalities (UNO, DOS, STD-P)
    • IP Grade:  IP20, dry location

    Tech Specs

    Optics:

    Light Source Type: LEDs

    Light Source Wattage: 50 W (2 A)w

    Minimum Beam Angle: 8.0°

    Maximum Beam Angle: 51.0°

    Control

    DMX Channel Modes: 3 personalities (UNO, DOS, STD-P)

    DMX 3-Pin Connectors?: Yes

    DMX 5-Pin Connectors?: Yes

    Physical:

    Length: 12.8 in

    Width: 11 in

    Height: 16.5 in

    Weight: 13 lb

    Electrical

    Voltage Range: 100 to 240 VAC

    Power Cable Connector - Fixture Side: Neutrik® powerCON®

    Main Power Connector on Included Cable: Local plug to Neutrik® powerCON®
