Ovation Reve E-3 (White housing)

The Ovation Rêve E-3 is a multi-color LED ellipsoidal, that features high quality whites and smooth transitions. This fixture would be greate on medium and larger stages.

This is the white-housing version and is available for special order, with a minimum quantity requirement.  This page will show "sold out", but we can get them.  Contact us for more info.

From the Manufacturer:

Ovation Rêve E-3 is the brightest, multi-color LED ellipsoidal that also has the capability of producing perfectly tunable whites. It’s a new kind of epic story-telling machine that fuses the best of both worlds into one totally reimagined LED light source. Color Temperature presets ranging from 2800K to 8000K maintain outstanding brightness and a high quality of light, with an emulated “red shift” for a tungsten feel. Ovation Rêve E-3 also features several dimming curves, a virtually silent operation with fan-off modes, and a series of technician-friendly features such as an innovative, adjustable yoke that makes mounting in low clearance situations a breeze. With Ovation Rêve E-3 you can seamlessly transition from captivating a wide range of saturated colors in class-leading output to distinct whites with +/- green adjustments using one fixture. No ifs, or buts. Simply and categorically unrivaLED.

Features:

• Full-spectrum LED ERS-style lighting fixture for theatre, film and production

• Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS

• Virtual color wheel with color matched to popular gel colors

• +/- Green adjustment and emulated red-shift via DMX or on-board control

• RDM (Remote Device Management) for added flexibility

• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera

• Virtually silent operation for use in studio, film and theatre applications

• Ultra-smooth 18-bit dimming curves and speeds to complement any lighting scheme.

• Innovative adjustable yoke for mounting in low clearance areas

• Direct power/data connection and control options for the Ovation GR-1 gobo rotator

• USB port for fixture software updates

Specifications:

• Optical

• Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy (L70)

• Color Temperature (range): 2800 to 8000 K

• Color Temperature (at full): 5470K

• CRI (3200 K): 95.4

• Beam Angle (w/5° lens): 4.6°

• Beam Angle (w/10° lens): 10°

• Beam Angle (w/14° lens): 14.8°

• Beam Angle (w/19° lens): 18.5°

• Beam Angle (w/26° lens): 26°

• Beam Angle (w/36° lens): 33.3°

• Beam Angle (w/50° lens): 49.5°

• Beam Angle (w/15°–30° lens)(Narrow): 13°

• Beam Angle (w/15°–30° lens)(Wide): 28.5°

• Beam Angle (w/25°–50° lens)(Narrow): 23.6°

• Beam Angle (w/25°–50° lens)(Wide): 40.5°

• Field Angle (w/5° lens): 5.6°

• Field Angle (w/10° lens): 11.1°

• Field Angle (w/14° lens): 16°

• Field Angle (w/19° lens): 21.6°

• Field Angle (w/26° lens): 29.6°

• Field Angle (w/36° lens): 37.1°

• Field Angle (w/50° lens): 55.7°

• Field Angle (w/15°–30° lens)(Narrow): 15.4°

• Field Angle (w/15°–30° lens)(Wide): 32.2°

• Field Angle (w/25°–50° lens)(Narrow): 25.8°

• Field Angle (w/25°–50° lens)(Wide): 44.1°

• Lumens (w/5° lens): 5,076

• Lumens (w/10° lens): 11,250

• Lumens (w/14° lens): 12,179

• Lumens (w/19° lens): 12,156

• Lumens (w/26° lens): 13,300

• Lumens (w/36° lens): 13,223

• Lumens (w/50° lens): 12,216

• Lumens (w/15°–30° lens): 12,057

• Lumens (w/25°–50° lens): 14,355

• Illuminance (w/5° lens): 31,856 lux @ 5 m

• Illuminance (w/10° lens): 18,924 lux @ 5 m

• Illuminance (w/14° lens): 9,284 lux @ 5 m

• Illuminance (w/19° lens): 5,635 lux @ 5 m

• Illuminance (w/26° lens): 3,378 lux @ 5 m

• Illuminance (w/36° lens): 2,085 lux @ 5 m

• Illuminance (w/50° lens): 870 lux @ 5 m

• Illuminance (w/15°–30° lens)(Narrow): 9,292 lux @ 5 m

• Illuminance (w/15°–30° lens)(Wide): 2,671 lux @ 5 m

• Illuminance (w/25°–50° lens)(Narrow): 3,710 lux @ 5 m

• Illuminance (w/25°–50° lens)(Wide): 1,527 lux @ 5 m

• Barrel Rotation: +/- 25°

• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz



• Dynamic Effects

• Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy (L70)

• Color Temperature (range): 2800 to 8000 K

• Color Temperature (at full): 5470K

• CRI (3200 K): 95.4

• Beam Angle (w/5° lens): 4.6°

• Beam Angle (w/10° lens): 10°

• Beam Angle (w/14° lens): 14.8°

• Beam Angle (w/19° lens): 18.5°

• Beam Angle (w/26° lens): 26°

• Beam Angle (w/36° lens): 33.3°

• Beam Angle (w/50° lens): 49.5°

• Beam Angle (w/15°–30° lens)(Narrow): 13°

• Beam Angle (w/15°–30° lens)(Wide): 28.5°

• Beam Angle (w/25°–50° lens)(Narrow): 23.6°

• Beam Angle (w/25°–50° lens)(Wide): 40.5°

• Field Angle (w/5° lens): 5.6°

• Field Angle (w/10° lens): 11.1°

• Field Angle (w/14° lens): 16°

• Field Angle (w/19° lens): 21.6°

• Field Angle (w/26° lens): 29.6°

• Field Angle (w/36° lens): 37.1°

• Field Angle (w/50° lens): 55.7°

• Field Angle (w/15°–30° lens)(Narrow): 15.4°

• Field Angle (w/15°–30° lens)(Wide): 32.2°

• Field Angle (w/25°–50° lens)(Narrow): 25.8°

• Field Angle (w/25°–50° lens)(Wide): 44.1°

• Lumens (w/5° lens): 5,076

• Lumens (w/10° lens): 11,250

• Lumens (w/14° lens): 12,179

• Lumens (w/19° lens): 12,156

• Lumens (w/26° lens): 13,300

• Lumens (w/36° lens): 13,223

• Lumens (w/50° lens): 12,216

• Lumens (w/15°–30° lens): 12,057

• Lumens (w/25°–50° lens): 14,355

• Illuminance (w/5° lens): 31,856 lux @ 5 m

• Illuminance (w/10° lens): 18,924 lux @ 5 m

• Illuminance (w/14° lens): 9,284 lux @ 5 m

• Illuminance (w/19° lens): 5,635 lux @ 5 m

• Illuminance (w/26° lens): 3,378 lux @ 5 m

• Illuminance (w/36° lens): 2,085 lux @ 5 m

• Illuminance (w/50° lens): 870 lux @ 5 m

• Illuminance (w/15°–30° lens)(Narrow): 9,292 lux @ 5 m

• Illuminance (w/15°–30° lens)(Wide): 2,671 lux @ 5 m

• Illuminance (w/25°–50° lens)(Narrow): 3,710 lux @ 5 m

• Illuminance (w/25°–50° lens)(Wide): 1,527 lux @ 5 m

• Barrel Rotation: +/- 25°

• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

• Construction/Physical

• Dimensions (fixture only, yoke up): 20.44 x 13.07 x 20.53 in (519 x 332 x 522 mm)

• Dimensions (w/5° lens extended, yoke up): 41.60 x 14.17 x 21.42 in (1056 x 360 x 544 mm)

• Dimensions (w/10° lens extended, yoke up): 32.87 x 13.07 x 20.01 in (835 x 332 x 510 mm)

• Dimensions (w/14° lens extended, yoke up): 29.7 x 13.07 x 20.53 in (755 x 332 x 522 mm)

• Dimensions (w/19°, 26°, 36° or 50° lens extended, yoke up):26.83 x 13.07 x 20.53 in (681 X 332 X 522 mm)

• Dimensions (w/15°–30° lens, yoke up): 33.02 x 13.52 x 20.53 in (839 x 343 x 522 mm)

• Dimensions (w/25°–50° lens, yoke up): 25.74 x 13.52 x 20.53 in (838 x 343 x 522 mm)

• Weight (fixture only): 18.6 lb (8.4 kg)

• Weight (w/5° lens): 26 lb (11.7 kg)

• Weight (w/10° lens): 24 lb (10.8 kg)

• Weight (w/14° lens): 25.6 lb (11.6 kg)

• Weight (w/26° lens): 24.2 lb (10.9 kg)

• Weight (w/15°–30° lens): 32.3 lb (14.6 kg)

• Weight (w/25°–50° lens): 29.8 lb ( 13.5 kg)

• Exterior Color: Black or White

• Gobo Size (Optional): “A”: 100 mm (outside), 75 mm (image), 2.5 mm (max. thickness)

• Gobo Size (Optional): “B”: 86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness)

• Accessory Holder/Gel Frame Size (5° lens): 14 in (356 mm)

• Accessory Holder/Gel Frame Size (10° lens): 12 in (304 mm)

• Accessory Holder/Gel Frame Size (14° lens): 7.5 in (191 mm)

• Accessory Holder/Gel Frame Size (19°, 26°, 36°, and 50° lens): 6.25 in (159 mm)

• Accessory Holder/Gel Frame Size (15°–30° lens): 7.5 in (191 mm)

• Accessory Holder/Gel Frame Size (25°–50° lens): 7.5 in (191 mm)

• Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65

• Power Input: Seetronic Powerkon IP65

• Power Output: Seetronic Powerkon IP65

• Data Connectors: 3- and 5-pin XLR

• Cable Length (power): 5 ft (1.5 m)

• Software Connection: USB

• Control

• Control Protocol: DMX, RDM

• DMX Channels: 1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV

• Modes/Personalities: 9 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, 18, HSV)

• Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

• Power Linking: 4 units @ 120 V; 7 units @ 208 V; 8 units @ 230 V

• Power and Current: 367 W, 3.04 A @ 120 V, 60 Hz

• Power and Current: 356 W, 1.76 A @ 208 V, 60 Hz

• Power and Current: 353 W, 1.59 A @ 230 V, 50 Hz

• Certifications/Qualifications

• CE, MET, FCC

• IP Rating: IP20, dry location

• Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

What’s Included?

• Ovation Reve E-3

• Seetronic Powerkon power cord

• Ovation Metal Gobo Holder

• Soft Focus Filter

Required Accessories

• Lens Tube: 5°, 10°, 14°, 19°, 26°, 36°, 50°, 15°-30°, 25°-50°

Optional Accessories:

• Professional Clamps: CTC-50HC, CTC-50HCN

• Safety Cable: SC-07

• TRUE1 Style Power Extension Cables

• 3-pin or 5-pin DMX Cables

• Color Blending Filters: DF60X1D, DF20D

• RDM2go

• Ovation Glass Gobo Holder

• Ovation Metal Gobo Holder

• Ovation Iris

• USB Jump Drive
