NEEDS FIXED Radial Catapult RX

The Radial Catapult RX is a passive analog audio receiver that transports up to 12 channels of balanced audio over standard Cat 5e or Cat 6 cable. Designed for live sound, broadcast, and installation applications, it provides a reliable and cost-effective alternative to traditional multicore snakes while maintaining excellent analog audio quality.

From The Manufacturer

The Catapult RX is part of Radial's Catapult analog audio snake system, receiving up to 12 channels of balanced analog audio over three shielded Cat 5/6 cables. It is fully passive, requiring no power or digital conversion, and integrates seamlessly with other Catapult modules for flexible stage, studio, and installation setups.

Key Features

• Passive analog audio receiver

• Transmits up to 12 balanced analog or AES signals over Cat 5e/Cat 6 cable

• 12 male XLR outputs

• 6 Neutrik etherCON RJ45 connectors (Input/Thru)

• Three banks of four audio channels

• Ground lift switch for each bank

• No power supply required

• Compatible with all Radial Catapult modules

• Reversible rack ears for flexible installation

• Rugged steel construction for touring applications

Specifications

• Product Type: Passive Analog Audio Snake Receiver

• Audio Channels: 12

• Audio Circuit: Passive

• XLR Connectors: 12 × 3-pin Male

• RJ45 Connectors: 6 × Neutrik etherCON

• Frequency Response: 10 Hz – 100 kHz (±0.05 dB)

• Total Harmonic Distortion: <0.0003%

• Signal-to-Noise Ratio: >114 dB

• Dynamic Range: 136 dB

• Maximum Input Level: +20 dBu

• Construction: 18-gauge Steel Chassis, 12-gauge Steel Faceplate

• Rack Size: 19-inch, 1 RU

Included

• Radial Catapult RX

• User documentation

Applications

• Live sound

• Broadcast

• Recording studios

• Theatre

• Houses of worship

• Touring productions

• Corporate AV

• Fixed audio installations

Included Accessories

• User documentation

Accessories (Not Included)

• Radial Catapult TX

• Shielded Cat 5e/Cat 6 Ethernet cables

• XLR audio cables

• Rack mounting hardware (if not supplied)

Size

• 19 × 3.25 × 1.75 in (483 × 83 × 44 mm, 1 RU)

Weight

• 1.39 kg (3.06 lb)

Electrical/Thermal

• Passive design

• No external power required

• Operating temperature: Manufacturer specification not available
