SL-350 Slim Line light weight UPS

The Juice Goose SL-350 is a thin and light battery backup device (UPS) ideal for installation in cabinets, kiosks and other small spaces.

From the Manufacturer

The SL-350 is a battery backup device (UPS) that features advanced lithium ion (LiFe) battery technology to achieve a light weight and thin profile design. Measuring only 6.9" x 8.5" x 1.25", this  UPS is well suited for installation in small spaces previously impractical for an ordinary UPS. Learn more about these batteries.

In the commercial audio video market, the SL-350 provides power continuity to support video projectors and digital signage components. This product is also well suited for installation in kiosks, cabinets and small enclosures. In other markets, it has a convenient form for point of sale equipment.

This UPS has a power rating of 200 watts (350 VA). With a maximum electrical power load connected and with the UPS batteries fully charged, the unit will provide continuous electric power for approximately six minutes in the event of a utility power failure (blackout). The amount of time power is available  increases as the connected load decreases. In addition to battery power, the SL-350 features 312 Joules of AC power surge protection.

The SL-350 is designed to be used with a detachable power cord. A three foot cord with a right angle plug is provided with the unit. Should a different length or style of cord be needed for a particular installation or application one can be purchased at-large and installed into this UPS. That cord should have a NEMA 5-15P plug as well as a female IEC style connector to attach to the UPS. The chassis is designed to make mounting to a wall or surface easy and reliable.

Specifications

• Power Capacity (VA): 350
• Power Capacity (Watts): 200
• Rack Height: N/A
• Weight (Net, Lbs): 3.4
• Run Time, Full Load (Min): 6
• Run Time, Half Load (Min): 14
• Input:
  • Voltage: 120 VAC
  • Frequency: 50 or 60 Hz
• Output:
  • Voltage: 120 VAC
  • Waveform (Battery): Simulated sine wave
  • Frequency: 50 or 60 Hz Output.
• Battery:
  • Type: Lithium Iron Phosphate (LiFePo4)
  • Style: 18650
  • Quantity: 8
  • Run time: 6 mins. full load, 14 mins, half load
• Dimensions (inches): 6.9W x 8.5D x 1.25H
• Weight: 3.4 lbs : 3 foot, C13 (IEC) to 5-15P (NEMA) right angle
• Receptacles: 3 x 5-15R
• Environment:
  • Operating Temperature Limits: 32 to 104 degrees F
  • Operating Humidity Limits: 0 to 90% RH
  • Operating Altitude Limit: 11,500 feet over sea level
• Power Control: Push button on/off
• Communications Port: USB
• Warranty: 3 years electronics and batteries (USA and Canada)
• Certification: UL-1778, cTUVus, FCC, and RoHS
