AC895

The AC895 is a full range speaker small to medium install applications. It can be a great option for those looking for an easy cost effective solution.

From the Manufacturer:

AC895 is a compact 2-way full-range loudspeaker system comprised of one 209 mm (8 in) low frequency driver and one 25 mm (1 in) exit/25 mm (1 in) voice-coil compression driver. The rotatable PT™ Progressive Transition waveguide provides 90° by 50° coverage in vertical cabinet orientation. Highslope passive crossovers minimize band overlap and well-controlled offaxis response. The cabinet is fitted with M10 threaded suspension points. Four threaded inserts located on back of the enclosure allow attachment of an MultiMount® or similar type mounting. AC895 is part of JBL's AE Application Engineered Series, a versatile family of loudspeakers for a wide variety of fixed installation applications

Features:

• Compact enclosure

• 209 mm (8 in) LF transducer

• 90° x 50° Progressive Transition™ Field Rotatable Waveguide with a 25 mm (1 in) exit 25mm (1") diaphragm compression driver

• Dual Neutrik NL4 connectors plus screw terminals

• Multiple Attachment Points for Ultimate Flexibility

Applications:

• Performing Spaces

• Clubs & Bars

• Houses of Worship

• Multi Media Spaces

• Retail & Hospitality Spaces

• Presentation Suites

• Educational Facilities

Specifications:

• Frequency Range (-10dB)

• 70 Hz - 20 kHz

• Frequency Response (±3 dB)

• 90 Hz - 18 kHz

• System Sensitivity (1w @ 1m)

• 94 dB

• Nominal Impedance

• 8 ohms

• Maximum SPL (1m)

• 116 dB (122 dB peak)

• System Power Rating

• 250W (1000W peak), 2 hrs (AES rated)

• 150 W/300 W/600 W (Continuous/Program/Peak) (IEC rated)

• Coverage Pattern

• 90° x 50° (H x V)

• Crossover

• 2 kHz

• LF Driver

• 1 x 8" woofer (P/N: 5055470), 209 mm (8 in) driver with 50 mm (2 in) voice-coil

• HF Driver

• 1 x 2414H-C driver with 25 mm (1 in) exit/25 mm (1 in) voice-coil

• Input Connector

• Dual Neutrik NL4MP connectors plus covered barrier trip terminals

• Enclosure

• 15 mm multi-ply hardwood plywood

• Grille

• Powder coated, 1.5mm perforated steel, with acoustically transparent black foam backing

• Finish

• Textured black paint finish. White (-WH) available upon request. Not available with WRC & WRX finish.

• Suspension Attachment

• 14 x M10 and 4 x M10 for Wall Mount Bracket. Optional U-bracket, L-bracket and wall-mount bracket

• Dimensions (H x W x D)

• 470 mm x 265 mm x 254 mm 18.5 in x 10.4 in x 10.0 in

• Net Weight (each)

• 10.2 kg (22.4 lbs)

• Crossover Modes4

• Passive

• Nominal LF Driver Impedance

• 8 ohms

• Nominal HF Driver Impedance

• 8 ohms
