Active DI Box

The DB1000 active DI box converts a 1/4" instrument signal to a balanced XLR output for connection to mixers or PA systems. It includes a pad switch and ground lift to help manage signal level and noise on stage or in the studio. The metal enclosure is built for regular live and recording use.

From The Manufacturer:

Our DB1000 Active DI Box converts any high-impedance 1/4" source to a low-impedance XLR signal ready to send via a long cable run to a mixer or PA system. Features include a -15 dB pad switch to prevent clipping, a throughput connector to pass unaltered signal to a stage amp, and a ground-lift switch to defeat ground-loop hum. Its heavy-duty metal enclosure protects the internal components and ensures reliable performance.

Features:

• Converts a high-impedance (1/4") input to a balanced, low-impedance (XLR) output

• Output signal can be sent via a long cable to a mixer or PA system without frequency loss

• Active circuit features a high-quality transformer for low distortion and an isolated signal path

• -15 dB pad switch prevents clipping

Specification:

• Application

• Acoustic guitars, bass guitars, keyboards, and more

• Construction

• Metal w/ nylon bumpers

• Dimensions

• 6" x 3.5" x 1.5"

• Frequency Response

• 10Hz - 40kHz

• Ground lift

• Yes

• Input Resistance

• 220K Ohms

• Inputs

• 1/4"

• Output

• XLR

• Pad

• 15dB

• Power

• Phantom

• Product Type

• Direct Box

• Weight

• 0.70 lb
