Mamba IP65 500W Beam

The Ayrton Mamba is an incredibly versatile beam light fixture, with groundbreaking effects and unmatched graphic capabilities, for endless options indoors or outdoors.

From the Manufacturer:

After the global triumph of Cobra—sold in thousands across the world—Ayrton unveils Mamba, a groundbreaking, versatile lighting concept.

Equipped with a laser source twice as powerful, Mamba delivers a multitude of breathtaking new psychedelic effects that are nothing short of spectacular. Mamba boasts unmatched graphic capabilities, featuring 18 motors dedicated solely to effect creation. It offers a vast selection of 92 fixed and rotating metal gobos across two wheels, specifically designed to sculpt light in “beam” mode. An endlessly rotating ovoid animation wheel adds to its dynamic arsenal. The gobos can be paired with an initial level of two palettes, each containing four individually rotating prisms that can be combined. These can then be linked to a second level of four combinable prisms situated at the front of the fixture, enabling the creation of a multitude of complex volumetric effects. Completing its graphic toolkit are two Frost filters. Mamba introduces a highly innovative colour section, including a brand-new high-definition gradient CMY mixing system and an instant-access multi-position wheel equipped with 15 complementary colour filters, two multicolour filters, two CTP correctors, a progressive CTO, and three multicolour sections – RGB, CMY, and RGB+CMY – spread over two concentric circles.

Fitted with a 250 mm front lens, the proprietary 13-lens optical system offers a 21 x zoom range and an operating span from 0.7 ° to 15 °, pushing the boundaries of beam definition with a native contrast unparalleled by any digital light source.

Mamba features an extreme focusing range that allows you to adjust the beam shape based on the operating distance. With continuous pan and tilt rotation multiplying the possibilities for creating complex effects, this fixture becomes a universal tool capable of tackling any challenge in any condition. Developed as a versatile fixture, Mamba operates flawlessly both outdoors and indoors—even in saline environments—while maintaining full accessibility and an incredible weight of just 41 kg. It’s equipped with a sun protection system and an integrated heating system that withstands temperatures as low as -20 °C (-4 °F).

Specifications:

• OPTICS
  • 13-element 21:1 zoom high-resolution optic system
  • Beam aperture: 0.7 ° to 15 °
  • Fast motorised linear zoom
  • Tempered anti-reflective coated lenses
  • 250 mm frontal lens for greater performance
• LIGHT SOURCE
  • Luminous flux: 2,600,000 lux at 10 m
  • Colour temperature output: 9000 K
  • Rated life (L70): up to 12,000 hours
  • Speckle-free source
• MOVEMENT
  • Highly accurate positioning
  • Moving-head operated via either 8- or 16-bit resolution
  • High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
  • Pan and tilt automatic repositioning
  • Moving-head range: infinite pan and tilt rotation
• COLOURS
  • Sophisticated colour mixing system providing CMY color mixing
  • Fixed colour wheel with variable CTO, 15 complementary colour filters, 2 minus green filters, 2 multicolour filters and 3 coloured animation sections
• GOBOS
  • One indexable rotating gobo wheels with 12 Quartz glass gobos, plus open position
  • Adjustable-speed rotating gobo in both directions
  • Fixed multi-position gobo wheel with instant access to 80 metal gobos
  • Gobo diameter: 6.9 mm
  • Image diameter: 4 mm
• FROST
  • 2 frost filters: one light, one heavy
• EFFECTS
  • Monochromatic graphical animation effects wheel with continuous rotation in both directions
  • 2 set of 4 combinable rotating and indexable prisms
  • 2 extra set of 2 combinable rotating and indexable prisms
• DIMMER / STROBE
  • Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
  • Strobe effect, with speed adjustment from 1 to 25 flashes per second
• SOFTWARE FEATURES
  • Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel
  • Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller
  • Information menu including hour counter, temperature, software version
• HARDWARE FEATURES
  • Graphic LCD display for addressing and special functions settings, with flip function
  • 5 menu buttons to set functions
  • Excess temperature protection
  • Integrated wireless CRMX TiMo RDM receiver from LumenRadio
  • IP65 XLR 5 pin male and female connectors for DMX connection
  • IP65 RJ45 IN / OUT connectors for ArtNet connection
  • IP65 PowerCON TRUE1 TOP male connectors for power connection
• CONTROL
  • DMX 512 protocol, through DMX cable or a wireless system
  • DMX-RDM compatible
  • Stand-alone mode and Main/Follow modes
  • ArtNet & sACN protocol through Ethernet cable
  • Local control panel, with IP65 LCD display
  • Footprint of 47 DMX channels
• POWER SUPPLY
  • Electronic supply with active PFC
  • 100 to 240 Volts – 50/60Hz
  • Power: 800 W maximum
• COOLING SYSTEM
  • Advanced liquid cooling system
  • Self-adjusting variable speed fans for quiet operation (Auto mode)
  • Selectable ventilation user modes with a new Silent Mode
  • Safety protection against excess temperature
• HOUSING
  • Moving-head skeleton made of aluminium and steel metal plates
  • Base and head in die-cast aluminium
  • Heatsinks in aluminium and copper
  • Arms in self-extinguishing fire retardant ABS PC (V0 class)
  • Four-side handles for transportation
  • Four heavy-duty feet for better stability
  • IP65 protection rating
  • Exterior finish: black (Carbon)
• INSTALLATION
  • Fastening bracket system: two Omega ¼ turn brackets designed for use with standard clamps
  • Mounting points: four ¼ turn locking fittings allowing installation of Omega brackets on luminaire
  • Safety cable attachment point
• OPERATING PARAMETERS
  • Operating positions: all (device on floor or fixed to a support)
  • Maximum permitted ambient temperature (Ta max): 45 °C (113 °F)
  • Minimum permitted ambient temperature (Ta min): -20 °C (-4 °F)
  • Minimum usage distance: 35 m (114.83 ft)
• COMPLIANCE
  • EU (EMC & LVD)
  • EMC Directive 2014/30/EU
  • LVD Directive 2014/35/EU
  • US (Safety & EMC)
  • UL 1573
  • FCC Part 15, Subpart B: 2018
• SIZE
  • Product: 405 x 747 x 369 mm (l x h x d)
  • Flight-case foam: 680 x 500 x 640 mm (l x h x d)
• WEIGHT
  • Product: 41 kg
