4KSH: 4K 12G-SDI to HDMI Converter with Audio Extraction

The BZBGEAR BG-4KSH is a 12G/6G/3G/HD-SDI to HDMI 2.0 converter with audio extraction, for professional signal conversion.

From the Manufacturer:

The BZBGEAR BG-4KSH is a 12G/6G/3G/HD-SDI to HDMI 2.0 converter with audio extraction. The SDI signal is digitally converted into HDMI, guaranteeing lossless conversion for both audio and video. Featuring up to 8 channels of audio, the BG-4KSH is compatible with 7.1 or 5.1 surround sound systems. The 3.5mm analog stereo output, SDI input, SDI loop-out, and HDMI output provides users convenient flexibility. With these robust features, the BG-4KSH can take SDI signals from professional or commercial AV equipment and effortlessly convert it to HDMI without compression for use of popular consumer-grade video interfaces.

Features:

• Crystal Clear Images: Stunning image quality up to 4K@60Hz
• HDMI Output: Convert SDI to HDMI the most popular video interface in the world
• SDI Loop-out: Loop out to view content locally at device
• Audio De-embedding: De-embed audio using a 3.5mm Stereo Mini input
• Status LEDs: See signal and power status at a glance with built in status lights
• Durable Metal Enclosure: Designed for years of reliable use
• 7.1 or 5.1 channel surround
• Convert signal from professional/commercial grade AV equipment to a more common interface
• Digital conversion of signal ensures lossless transformation for audio and video

Specifications:

• HDMI Compliance: 2.0
• SDI Formats:
  • SMPTE 2082; 11.88 Gbps / 12G-SDI: 2160p at 50/59.95/60 Hz
  • SMPTE 2081; 5.94 Gbps / 6G-SDI: 2160p at 25/29.97/30 Hz
  • SMPTE 424M-2.97 Gbps / 3G-SDI: 1080p at 50/59.94/60 Hz (4:2:2)
  • SMPTE 274M-1.485 Gbps / HD-SDI: 1080p at 23.98/24/25/29.97/30 Hz, 1080i at 50/59.94/60 Hz
  • SMPTE 292M-1.485 Gbps / HD-SDI: 1080i at 30 Hz, 720p at 60 Hz
  • SMPTE 296M-1.485 Gbps / HD-SDI: 720p at 23.98/24/25/29.97/30/50/59.94/60 Hz
• HDMI Formats: 4K UHD Video Standards / 2160p at 23.98/24/25/29.97/30/50/59.94/60 Hz
• UHD Video Standards / 1080p at 50/59.94/60 Hz (4:2:2)
• HD Video Standards / 720p at 50/59.94/60 Hz, 1080i at 50/59.94/60 Hz, 1080p at 23.98/24/25/29.97/30 Hz
• SDI Bitrate: 270 Mbps, 1.485 Gbps, 2.97 Gbps, 5.94 Gbps, 11.88 Gbps
• Video Sampling: 4:2:2
• Audio Sampling: 48 kHz & 24 bit
• Auto Switching: Auto switching between SD / HD / 3G / 6G / 12G-SDI
• Cable Reach:
  • 12G-SDI up to 70m (233ft)
  • 6G-SDI up to 100m (330ft)
  • 3G-SDI up to 190m (627ft)
  • HD-SDI up to 250m (825ft)
• Eye-patten Measurements:
  • Amplitude: within 800mV
  • Raise & Fall time: 45ps
  • Alignment jitter: <0.3 (100kHz to 1188MHz)
• ESD Protection:
  • 8 KV - Contact Discharge
  • 15 KV - Air Discharge

• Housing Design: Metal
• Casing Style: Wall Mountable
• Power Connection: Micro-USB Port
• Power Supply: 5V DC, 1A
• Power Consumption: 2.5 Watts (Max.)
• Operating Humidity: 20-90% RH (no condensation)
• Operation temperature: 32~104°F / 0~40°C
• Product Weight: 0.39 lb (175g)
• Package Weight: 0.86 lb (390g)
• Certifications: CE, FCC, RoHS
