Sku: NCDI4X12-U-US

CDi4x1200

Regular price
$4,347.00
Regular price
Sale price
$4,347.00
Shipping calculated at checkout.
Vendor: Crown

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

Buy now with ShopPay

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Description

Caret Down

The CDi4x1200 is an analog 4 channel speaker amplifier for  larger install purposes, that require high quality audio.

From the Manufacturer:

The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost.  Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 4|1200 offers streamlined functionality to work in almost any large sized installation such as cinema, houses of worship, hotels, cruise lines, and more.  Designed for ease-of-use in a variety of applications, the 4|1200 is a 4-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.

Specifications:

  • BLU link

    • No

  • Channels

    • 4

  • Sensitivity (for full rated power at 8 ohms)

    • 0.7V RMS

  • Rated Power Output (per channel @ 4 ohms)

    • 1200W

  • Analog Input Signal to Noise Ratio (ref. rated power, 100V, 20Hz - 20kHz) at 8 ohms)

    • > 104dB

  • THD (full rated power, 20 Hz - 20 kHz)

    • 0.35%

  • Damping Factor (20 Hz to 100 Hz)

    • > 1000

  • Frequency Response (8Ω, 20 Hz - 20 kHz)

    • +/-0.25dB

  • Crosstalk (below rated power) 20 Hz to 1 kHz

    • > 80dB

  • Input Impedance (nominally balanced, nominally unbalanced) 20 kΩ balanced, 10 kΩ unblanced

  • Dimensions (inches) (W x H x D) (depth not including 1.3 inch front panel protrusion)

    • 19 x 3.5 x 14.71

  • Weight

    • 20.1 lbs (9.12 kg)

  • Power Supply Connector

    • "20A IEC connector, 100 – 240V"

Tech Specs

CDi4x1200
CDi4x1200

$4,347.00
