Circa Giant Scoop

The Mega Light  Circa Scoop is a new wash and effects style light. It is ideal for creating breathtaking backlight effects.

From the Manufacturer:

MEGA-Lite presents a new addition to the Circa Scoop LED Series. This is our largest next-level unit designed with four different elements that can be used in multiple applications. With all the same great features of the rest of our Circa scoop line in one new gigantic package.

With a retro look and modern twist the Circa Giant Scoop LED takes the unique design and effects of our previous circa scoops to a whole new scale. Whether placed on the floor or rigged, this unique fixture can make any band or performer stand out from the rest.

Specifications:

• Housing:

• Sheet Metal

• Fastening System:

• 2 Quick Release Clamp Mounts, Hanging Yoke

• Power Connection:

• Seetronics SAC3MPX (Input)

• Seetronics SAC3FX (Output)

• Cable:

• Seetronics SAC3FX to Nema 5/15

• Signal Connection:

• 5 Pin XLR In and Out

• LED Angle:

• 140° (outer ring)

• Operating Temperature:

• Maximum ambient temperature 115°F

• Maximum surface temperature

• 135°F

• Fuse:

• 5x20mm F10AL250V

• LED Quantity

• 384 RGB Outer Ring, 288 Inner Ring, 80 Warm White + Amber Center, 180 Warm White Reflective

• LED Watts

• 0.8 Watts each

• Segments

• 8 outer segments, 8 inner segments

• Power Input

• 110-240VAC 50/60Hz

• Scan Rate

• 7000 Hz

• Power Supply

• 100-240 A/C

• Power Consumption

• 445 Watts

• 5.43Amps @110V

• Control Protocols:

• DMX 512

• RDM:

• Yes/No

• Channel Modes:

• 5 DMX modes

• LED Quantity:

• 384 RGB Outer Ring, 288 Inner Ring, 80

• Warm White + Amber Center, 180 Warm White Reflective

• LED Watts:

• 0.8 Watts each

• Segments:

• 8 outer segments, 8 inner segments 110-240VAC 50/60Hz

• Power Input:

• 100-240 A/C @ 50/60Hz

• Scan Rate:

• 7000 Hz

• Power Supply:

• 100-240 A/C

• Power Consumption:

• 445 Watts

• 5.43Amps @110V

• Fixture Size:

• 39.37" X 27.92" X 34"

• Fixture Weight:

• 51lb

• Packaged Size:

• 42" X 25 3/8" X 48

• Packaged Weight:

• 160lb
