Color STRIKE M

This is a versatile fixture that can be used as a strobe or a wash fixture. It has a pixel-mappable face that can be used to make breathtaking designs. This fixture is great for use on medium and larger stages when multiple are used.

From the Manufacturer:

Color STRIKE M is an IP65 rated motorized strobe/wash with two ultra-bright, white light tube elements surrounded by an electrifying, color-mixing, and pixel-mappable face. This versatile strobe light can double as a wash fixture with 180° tilt range to throw bright saturated color wherever you need. The IP65 casing protects the fixture from any environmental factors or weather and has two omega-bracket attachments so you can mount the fixture horizontally or vertically without any hassle. Multiple programming personalities give you a varying amount of control from simple set ups with a multitude of built-in effects, or wider control options to take advantage of the pixel-mappable zones: 14 in the RGB face and 28 in the two tube elements. Built-in alignment pins insure perfectly straight linear arrays to create massive arrangements. DMX, Art-net, and sACN control. All LEDs feature 16-bit dimming for smooth fades and Pulse Width Modulation for on-camera use.

Features:

• High-power, 180° tilting hybrid strobe/wash with IP65 rating for all-weather use.

• 14 controllable sections of RGB LEDs and 28 sections of control of the white strobe LEDs.

• Multiple mounting locations and repositionable yoke with ¼ turn adaptors for creative and convenient rigging options in vertical and horizontal orientations

• Multitude of built-in effect macros with control parameters

• DMX, ArtNet and sACN control capability

• 16-bit dimming control for smooth, perfect fades

• Easy to use OLED display

• Rugged design for years of rough use in the most extreme conditions.

• Adjustable Pulse Width Modulation (PWM) and RDM (Remote Device Management) for added flexibility

• USB port for fixture software updates

• Built-in alignment pins to insure perfectly straight linear arrays

Specifications:

• Optical

• Light Source: 896 LEDs (tri-color) SMD 5050, 0.784 W, (252 mA), 50,000 hours life expectancy

• Light Source: 432 LEDs, (CW) 1.56 W, (696 mA), 5861K, 50,000 hours life expectancy

• Color Temperature (at full): 7757 K

• CRI: 90.3

• Beam Angle (Combine): 98° x 57°

• Beam Angle (Plate): 123°

• Beam Angle (Beam): 95° x 50°

• Field Angle (Combine): 146° x 122°

• Field Angle (Plate): 160°

• Field Angle (Beam): 138° x 100°

• Lumens (Combined): 71,620

• Lumens (Plate): 18,600

• Lumens (Beam): 54,381

• Illuminance (Combined): 1591 lux @ 5 m

• Illuminance (Plate): 231 lux @ 5 m

• Illuminance (Beam): 1432 lux @ 5 m

• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

• Dynamic Effects

• Tilt: 180°

• Tilt Ranges: 0° to 180°

• Dimmer: Electronic

• Shutter/Strobe: Electronic

• Strobe Rate: 0 to 30 Hz

• Standalone Color Mixing: Yes

• Dim Modes: 4

• Built-in Automated Programs: Yes

• Construction/Physical

• Dimensions: 16.02 x 6.90 x 12.30 in (407 x 175.4 x 312.5 mm)

• Weight: 26.6 lb (12.1 kg)

• Exterior Color: Black

• Housing Material: Magnesium alloy

• Connections

• Power Connection: Edison (Local) plug to Seetronic Powerkon IP65

• Power Input: Seetronic Powerkon IP65

• Data Connectors: 5-pin IP65 XLR, Seetronic etherCON IP65

• Cable Length (power): 5 ft (1.5 m)

• Control

• Control Protocol: Art-Net, DMX, RDM, sACN

• DMX Channels: 8, 11, 13, 24, 30, 47, 74 or 97

• Art-Net Channels: 8, 11, 13, 24, 30, 47, 74 or 97

• Modes/Personalities: 8 personalities (8, 11, 13, 24, 30, 47, 74, 97)

• Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)

• Power and Current: 720 W, 7.14 A @ 100 V, 60 Hz

• Power and Current: 740 W, 6.36 A @ 120 V, 60 Hz

• Power and Current: 716 W, 2.35 A @ 208 V, 60 Hz

• Power and Current: 696 W, 3.27 A @ 230 V, 50 Hz

• Power and Current: 709 W, 3.02 A @ 240 V, 50 Hz

• Certifications/Qualifications

• CE, MET, FCC,

• IP Rating: IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve

• Temperature (Ambient): 14 °F to 113 °F (-10 °C to 45 °C)

• What’s Included

• Optional Accessories

What’s Included

• Color STRIKE M

• Seetronic Powerkon IP65 power cord

• Omega bracket
