Sku:
1190
Framebot 600
Regular price
$6,999.99
Regular price
Sale price
$6,999.99
Unit price
per
Shipping calculated at checkout.
Vendor: Mega Lite
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
The Framebot 600 is a full-featured automated luminaire with robust features packed into a medium-sized housing. This theatrical and production-grade unit is equipped with a 600W 7000K LED that produces an output of over 20,500 lumens (@ approximately 45ft). Featuring CMYK color mixing, the unit produces a broad range of pastel shades to rich saturated hues. The Colormation™ combines the effect of an animation wheel with vibrant colors that can be used to create an abstract motion effect.
With an advanced 4-blade framing system that features a 2pt pivot per blade and 180º framing rotation, the Framebot 600 allows for precise beam shaping. The impressive 6.5º-42º zoom range, 540º pan and 260º tilt, enhance versatility and efficiency. The rotating 4-facet prism can be used to intensify the 6 removable rotating gobos and 7 static gobos.
In the Box:
- (1) Framebot 600
- (2) Quick release clamp mounts (Clamps sold separately)
- (1) Power Cable
Features:
- Light Source: 580W LED
- Color Temperature: 7000K
- Beam Angle: 6.5 - 42
- Dimming: Electronic
- Refresh Rate: 50/60Hz
- Color: CYM, 6 color wheel + open, Colormation Wheel
- Gobo: 7 fixed + Open (Metal), 6 rotating (Glass)
- Effects: 4 Facet Rotating Prism, frost filter
- Framing: 4 blades with180 degree indexing
- Control Protocol: DMX, RDM
- Operating Modes: 39 Channels
- IP Grade: IP20
Tech Specs
Optics:
Light Source Type: LED
Light Source Wattage: 580w
Minimum Beam Angle: 6.5°
Maximum Beam Angle: 42.0°
Control
DMX Channel Modes: 39
DMX 3-Pin Connectors?: Yes
DMX 5-Pin Connectors?: Yes
Physical:
Length: 25.2 in
Width: 14.17 in
Height: 13.31 in
Weight: 56 lb
Electrical
Voltage Range: 100 - 240
Maximum Wattage: 800w
Power Cable Connector - Fixture Side: PowerCon
Main Power Connector on Included Cable: Edison
View full details
