Sku: COREPARQ120ILS

COREpar Q120 ILS

Regular price
$329.99
Regular price
Sale price
$329.99
Shipping calculated at checkout.
Vendor: Chauvet DJ

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Description

Caret Down

COREpar Q120 ILS is a 120-watt quad-color (RGBW) COB (Chip-on-Board) LED that produces a full spectrum of light with unsurpassed color mixing. Its robust housing withstands the harshness of traveling from gig to gig and its sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit for easy connections. Among the powerful features of the COREpar Q120 is ILS compatibility for use in the Integrated Lighting System (ILS) ecosystem that makes creating coordinated light shows across different fixture types easy. D-Fi USB compatibility is also board for wireless Master/Slave or DMX control. Achieve flicker-free video operation with high-frequency LED dimming and the included magnetic Fresnel lens allows the flexibility to go from ultra-wide to narrow beam in seconds. Create customized colors using the built-in LED display and achieve smooth LED fading with built-in dimming curves.


In the Box:

  • (1) COREpar Q120ILS
  • (1) IEC Power Cable
  • (1) Magnetic Lens

  Features:

  • Light Source: 1x 120W RGBA COB LED
  • Beam Angle: 56° (20° with lens)
  • Strobe: Variable
  • Color: RGBA
  • Control Protocol: DMX, D-Fi
  • Operating Modes: DMX, Standalone, ILS
  • IP Grade: IP20

Tech Specs

Optics:

Light Source Type: RGBA COB LED

Light Source Wattage: 120w

Minimum Beam Angle: 20.0°

Maximum Beam Angle: 56.0°

Control

DMX Channel Modes: 4 / 9

DMX 3-Pin Connectors?: Yes

DMX 5-Pin Connectors?: No

Physical:

Length: 8.9 in

Width: 7.4 in

Height: 9 in

Weight: 4.6 lb

Electrical

Voltage Range: 100 - 240 VAC 50/60Hz

Maximum Wattage: 100w

Power Cable Connector - Fixture Side: IEC

Main Power Connector on Included Cable: Edison

Warranty

Warranty: 2 Years

COREpar Q120 ILS
COREpar Q120 ILS

$329.99
