Sku: CVT10

NovaStar CVT10

$998.00
$998.00
Sold out
Shipping calculated at checkout.
Vendor: DVS LED

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Description

Caret Down

If you haven't purchased an LED wall before, please request a quote to ensure you build a complete system.

The CVT10 Converter is a cost effective solution to converting optical signals to electrical signals or visa versa. This converter is ideal for long distance transmissions. it is also a very practical design for on site instalations.

From the Manufacturer:

The CVT10 fiber converter offers a cost-effective way to convert optical signals to electrical signals, or electrical signals to optical signals, for connecting the sending card to the LED display. Delivering a full-duplex, efficient and stable data transmission that is not easily interfered with, this converter is ideal for long-distance transmission. The CVT10 hardware design focuses on the practicality and convenience of the on-site installation. It can be mounted horizontally, in a suspended way, or rack mounted, which is easy, secure and reliable. For rack mounting, two CVT10 devices, or one CVT10 device and a connecting piece can be combined into one assembly that is 1U in width.

Features:

  • Models include the CVT10-S (single-mode) and the CVT10-M (multi-mode).
  • 2x optical ports with hot-swappable optical modules installed at the factory, bandwidth of each up to 10 Gbit/s
  • 10x Gigabit Ethernet ports, bandwidth of each up to 1 Gbit/s
  • Fiber in and Ethernet out: 8x Ethernet ports available (ports 1–8), ports 9–10 currently unavailable (to beavailable in the future upgrade)
  • Ethernet in and fiber out: 10x Ethernet ports available
  • 2 types of power connectors, including a 3-pin power socket and a PowerCON socket
  • 1x type-B USB control port

In the Box:

  • (1) NovaStar CVT10
  • (1) Power cord

    Tech Specs

    Physical:

    Length: 254.3 mm

    Width: 50.1 mm

    Height: 290 mm

    Weight: 3.1 kg

    Electrical

    Voltage Range: 100-240V~, 50/60Hz, 0.7A

    Maximum Wattage: 22 Ww

    Main Power Connector on Included Cable: Edison
