Deco Drive CV4
- Regular price
- $749.00
- Regular price
-
- Sale price
- $749.00
- Unit price
- per
Shipping calculated at checkout.
Vendor: Mega Lite
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
Mega Lite's Deco system is a great houselight system for lower ceilings that you can install without an electrician in many municipalities. This is a driver with (4) outputs that can power/control (5) 19w lights per output for a total of 20 lights.
From the Manufacturer:
Using our innovative approach to simplify the need for multiple drivers, the DECO DRIVE CV4 was designed to control our popular DECO Series. This all in one solution features 4 outputs that gives users the ability to control multiple products at once.
Each output can be individually configured and addressed in any preferred channel. This powerful driver has a max power of 384W with 96W per output. The removable rack ears allow the unit to be wall, rack and rear rack mounted making it easy for various installations. Simplify your next project with the DECO DRIVE CV4!
From the GEAR Pro's:
We really like the Mega Lite Deco series for a few reasons. They're an affordable, high-quality LED houselight that runs on Cat6a cable (23awg). They offer a variety of different fixtures including recessed cans, pendants, sconces and more, and in most places you can install them yourself.
Mega Lite Deco systems consist of the DMX driver and the lights themselves. Each driver can control a different amount of lights, this one can control 20 of the pendant, sconce, or recessed lights in (4) runs of wire. Each run from the controller can have up to 5 lights on it and a maximum of 100' of cable. The Deco system also offers some other form factors of lights, which vary in wattage.
If you're looking to put a system together, let us know by filling out a quote request! We can help you determine how many drive boxes you need (and which ones), based on the amount of lights and layout you are doing.
Video Review:
In the Box:
- (1) Deco Drive CV4
- (1) Locking Power Cable
- (4) 5 Pin Screw Terminal Blocks
- (1) 2 Pin Screw Terminal Block
- (2) Rear & Wall Support Rack Ears
Features:
- Outputs: 4 x 96W
- Output Voltage: 24 VDC
- Output Connection: Screw Terminal or RJ45
- Refresh Rate: 4,000Hz
- Cooling: Convection
- Display: Digital
- Control Protocol: DMX
- Operating Modes: DMX, Standalone
Tech Specs
Control
DMX Channel Modes: 1 / 2 / 3 / 4 / 7
DMX 3-Pin Connectors?: No
DMX 5-Pin Connectors?: Yes
Physical:
Length: 19 in
Width: 10.37 in
Height: 1.75 in
Weight: 8.4 lb
Electrical
Voltage Range: 110 - 240 VAC 50/60Hz
Maximum Wattage: 384w
Power Cable Connector - Fixture Side: PowerCON
Main Power Connector on Included Cable: Edison
