Sku: DMX105

DMX 10-5 DMX Splitter

Name: DMX 10-5 DMX Splitter
Brand: OBSIDIAN Control Systems
SKU: DMX105
Price: 460.00 USD
Availability: InStock

$460.00

Sold out

Shipping calculated at checkout.

Vendor: OBSIDIAN Control Systems

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

Quantity

Description

A simple, rugged, flexible, 5-pin DMX splitter for non-RDM setups.

From the Manufacturer:

The DMX10-5 is a rackmount 10-port DMX Splitter with dual inputs and freely assignable 5pin XLR DMX outputs. Utilizing long life toggle switches every port is routed to either the A or B input, providing flexibility to accommodate any situation. The NETRON DMX10 is made from a rugged metal chassis featuring impact resistant paint and a lightweight yet solid construction. The DMX10 is ideally suited for installations and touring applications that do not require RDM communication and is available in 5 pin.

From the GEAR Pro's:

This is a 5-pin splitter. What I really like about it is that it has (2) DMX universes, and each port can be assigned to either universe with a little switch.

Other units on the market are fixed with 4/4 ports to each universe, some of them allow you to do all of the ports on (1) universe or split, but none offer this level of flexibility.

Need (5) ports of universe A and 7 ports of universe B? Done! (2) ports of universe A and (8) ports of universe B? You can do that too!

In the Box:

(1) Netron DMX 10-5
(1) 1.5m Locking power cable to Edison

Features:

Dual A/B 5pin XLR DMX Input
10 isolated 5pin XLR DMX Outputs
A/B routing per output port
LED feedback for In/Out/A/B/Power
Industrial strength powder-coated finish
Lightweight and rugged rackmount housing

Tech Specs

Control

DMX 3-Pin Connectors?: No

DMX 5-Pin Connectors?: Yes

Physical:

Length: 19 in

Width: 6.1 in

Height: 1.7 in

Weight: 3.31 lb

Electrical

Voltage Range: 100 - 240 VAC 50/60Hz

Power Cable Connector - Fixture Side: True1

Main Power Connector on Included Cable: Edison

View full details

DMX 10-5 DMX Splitter

$460.00
