DXL1K

The Yamaha DXL1K column-type powered speaker can be used as the main speaker in a compact PA system, and is also perfect for use as an extension of a STAGEPAS 1K mkII system.

From the Manufacturer:

The DXL1K is a column-type powered speaker with a powerful 125dB SPL peak@1m sound output that belies its extremely portable slim body (a dedicated carrying cart is sold separately).

The combination of an easy setup procedure that only requires the line-array speaker to be attached to the top of the subwoofer cabinet, with the system expandability offered by the Link function, allows the DXL1K to be used in combination with a compact mixer or with the fully compatible STAGEPAS 1K mkII, creating a simple, compact, and high-quality PA system.

Features:

• 1100W power output
• Biggest in the class 12-inch subwoofer for low frequency
• 1.5-inch x10 slim line array speaker for high frequency
• Easy-to-use 2-Channel Mixer
• Link in/out for expanding system
• Dedicated cover included
• Optional dolly (DL-SP1K) for more portability

Specifications:

• Speaker type: Powered subwoofer with a line array speaker
• Frequency range (-10dB): 37 Hz - 20 kHz
• Coverage area: H170ﾟ x V30ﾟ
• Crossover: 240 Hz
• Maximum output level (1m; on axis): 125 dB SPL
• Components: LF: Powered subwoofer: 12” (30 cm) Cone
• HF: Line array speaker: 1.5” (3.8 cm) Cone x 10
• Amplifier class: Class-D
• Power rating: Dynamic: 1100 W
• Power consumption: 25 W (Idle), 91 W (1/8 power)
• Power requirements: Depending on area of purchase: 100 V 50 Hz/60 Hz, 110-120 V 60 Hz, 220 V-240 V 50 Hz/60 Hz
• Processors: MODE (SPEECH/MUSIC/CLUB)
• I/O connectors: INPUT1: Combo x1 (mic/line), INPUT2: Combo x1 (line), LINK IN: XLR x1, LINK OUT: XLR x1
• Handle: Top of powered subwoofer x1
• Dimensions (W x H x D):
  • System: 334 x 2,000 x 418 mm (maximum)
  • Line array speaker: 67 x 582 x 86 mm
  • Powered subwoofer: 334 x 550 x 418 mm
  • Spacer: 67 x 555 x 86 mm (each)
• Weight: System: 23.0 kg (maximum), Line array speaker: 1.8 kg, Powered subwoofer: 20.0 kg, Spacer: 0.6 kg (each)
• Accessories: Power cord x1, Cover x1
• Options: Yamaha DL-SP1K (Dedicated dolly)
