EcoTou 1500.2

The Ashly EcoTour™ 1500.2 is a two-channel professional Class-D power amplifier designed for touring, live sound reinforcement, and permanent audio installations. Delivering up to 1,500 watts per channel into 2-ohm or 4-ohm loads, it combines high-efficiency amplification, flexible connectivity, selectable gain settings, and integrated protection features in a compact 2U rackmount chassis.

From The Manufacturer:

The Ashly EcoTour™ series is designed to deliver efficient, reliable amplification for professional audio environments. Its Class-D architecture and Dynamic Power Factor Correction (DPFC) support efficient power delivery, while the SailFlow cooling design helps manage heat during demanding operation.

The EcoTour 1500.2 provides two amplifier channels, supports low-impedance loudspeakers and compatible constant-voltage systems, and includes selectable input gain, switchable high-pass filters, and clip limiters. Its rackmount construction makes it suitable for touring systems and permanent sound installations.

Key Features:

1. Two-channel professional power amplifier.

2. High-efficiency Class-D amplifier design.

3. 1,500 W per channel at 2 Ω and 4 Ω.

4. 750 W per channel at 8 Ω.

5. Bridged output of up to 3,000 W.

6. Supports compatible 70 V and 100 V distributed audio systems.

7. Dynamic Power Factor Correction (DPFC).

8. Selectable amplifier gain settings per channel.

9. Adjustable front-panel input gain with lockout capability.

10. Switchable 80 Hz high-pass filter per channel.

11. Switchable clip limiter per channel.

12. Balanced XLR and ¼-inch TRS combo inputs.

13. Additional Euroblock input connections.

14. Neutrik speakON loudspeaker outputs.

15. Temperature-controlled fan cooling with SailFlow airflow design.

16. Front-panel indicators for power, signal, clipping, and protection.

17. Rugged 2U rackmount chassis.

18. Five-year manufacturer warranty, subject to applicable terms.

Specifications:

• Brand: Ashly

• Product Series: EcoTour™

• Model: 1500.2

• Product Type: Professional power amplifier

• Amplifier Class: Class D

• Number of Channels: 2

• Output Power at 2 Ω: 2 × 1,500 W

• Output Power at 4 Ω: 2 × 1,500 W

• Output Power at 8 Ω: 2 × 750 W

• Bridged Output at 4 Ω: 1 × 3,000 W

• Bridged Output at 8 Ω: 1 × 3,000 W

• 70 V Output: 2 × 1,500 W

• 100 V Output: 1 × 3,000 W in bridged mode

• Frequency Response: 20 Hz–20 kHz, ±0.05 dB

• Damping Factor: Greater than 250 at 8 Ω, below 1 kHz

• Signal-to-Noise Ratio: Greater than 103 dB, unweighted

• THD+N: Less than 0.5% under the manufacturer's specified test conditions

• Input Impedance: 10 kΩ

• Maximum Input Level: +21 dBu

• Input Connectors: XLR/¼-inch TRS combo connectors and 3.5 mm Euroblock

• Output Connectors: Neutrik speakON

• Input Gain Settings: 26 dB, 32 dB, 38 dB, or 1.4 V sensitivity

• High-Pass Filter: Switchable 80 Hz, second-order filter per channel

• Clip Limiter: Switchable per channel

• Cooling: Continuously variable, temperature-controlled fan system

• Rack Format: 2U

• Dimensions (W × H × D): 19 × 3.5 × 16.1 in (483 × 89 × 409 mm)

• Unit Weight: 16 lb (7.26 kg)

• Shipping Weight: 20 lb (9.08 kg)

Included Accessories:

• Ashly EcoTour™ 1500.2 power amplifier.

• AC power cable.

• Input block connectors, subject to the supplied package configuration.

Applications:

• Live sound reinforcement.

• Touring PA systems.

• Houses of worship.

• Theatres and performance venues.

• Concert halls and auditoriums.

• Conference centres.

• Commercial audio installations.

• Passive loudspeaker and subwoofer amplification.

• Distributed audio systems using compatible 70 V or 100 V loudspeakers.

• Professional sound systems requiring two channels of high-power amplification.

Included Accessories:

The amplifier uses an AC power connection and supports Euroblock input connections. Confirm the exact supplied cable, connectors, and package contents with the distributor.

Accessories (Not Included):

• Passive loudspeakers and subwoofers.

• XLR or ¼-inch audio signal cables.

• speakON loudspeaker cables.

• Equipment rack and rack hardware.

• External DSP processors or loudspeaker management systems, where required.

• Additional installation and cable-management accessories.

Size:

• Width: 19 in (483 mm)

• Height: 3.5 in (89 mm)

• Depth: 16.1 in (409 mm)

• Rack Height: 2U

Weight:

• Unit Weight: 16 lb (7.26 kg)

• Shipping Weight: 20 lb (9.08 kg)

Electrical/Thermal:

• Nominal Input Voltage: 100–240 V AC

• Frequency: 50–60 Hz

• Operating Voltage Range: 70–135 V AC at 110–120 V nominal; 140–270 V AC at 220–240 V nominal

• Power Supply: Switching power supply with active power-factor correction

• Power Consumption at One-Eighth Power: Approximately 485 W with all channels driven under the manufacturer's specified test conditions

• Current Draw: Approximately 4.2 A at 120 V AC, with all channels driven at one-eighth power

• Cooling: Continuously variable, temperature-controlled fan system

• Protection Features: Inrush-current limitation, over-temperature protection, output DC protection, output over-power protection, AC mains voltage protection, and mains fuses

• Operating Temperature: 32–120°F (0–49°C), non-condensing

• Power Connection: 20 A IEC connector; confirm the supplied power cable and plug type before installation.
