Sku:
EPIXDRIVE900
EPIX Drive 900
Regular price
$810.00
Regular price
Sale price
$810.00
Unit price
per
Shipping calculated at checkout.
Vendor: Chauvet Professional
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
ÉPIX Drive 900 hosts the processing and power supply for the ÉPIX Tour system. It supports either 18 ÉPIX Strip Tours or 6 ÉPIX Bar Tours, or any combination of the two, with a total capacity of 900 LEDs ÉPIX Drive 900 supports Art-Net, Kling-Net, and sACN, giving you a variety of control options. Thanks to an integrated web server, you can remotely diagnose, troubleshoot, and change settings as needed without having to directly access the ÉPIX lights.
In the Box:
- (1) ÉPIX Drive 900
- (1) Neutrik powerCON power cord
- (2) Rack ears
- (1) Bag of rack ear mounting screws
- (4) Rubber feet
Construction:
- Dimensions (with rack ears): 19.02 x 7.60 x 1.97 in (483 x 193 x 50 mm)
- Dimensions (without rack ears): 11.14 x 7.60 x 1.97 in (283 x 193 x 50 mm)
- Weight: 5.42 lb (2.46 kg)
- Threaded Bolt: M12
- Rack Space: 1U
- IP20
Control:
- Control Protocol: Art-Net, Kling-Net, sACN
- Control Channels: 6 Art-Net/sACN Universes
- Physical Linking: 18 inline ÉPIX Strip Tour or 6 inline ÉPIX Bar Tour
- Data Connectors: Neutrik etherCON
Power:
- Input Voltage: 100-240V, 50/60Hz (Auto Ranging)
- Power and Current: 299 W, 2.53A @ 120V, 60Hz
- Output Voltage: 48 VDC
- Maximum Load: 18 ÉPIX Strip Tour or 6 ÉPIX Bar Tour (per output)
Tech Specs
Physical:
Length: 19.02 in
Width: 7.6 in
Height: 1.97 in
Weight: 5.42 lb
Electrical
Voltage Range: 100-240
Maximum Wattage: 299w
Warranty
Warranty: 2 years
View full details
