GeNetix GN2 2 Port Node

The GeNetix GN2 is a Ethernet-DMX node for consoles that support Art-Net and sACN. This model is a great option for smaller applications.

From the Manufacturer:

GeNetix Node 2 is a two-port Ethernet-DMX node that is compatible with any console supporting Art-Net and sACN. GeNetix Node 2 can also be used as a USB interface for MagicQ PC systems, unlocking MagicQ into reduced mode when connected via its USB-C or Network port.

Configuration is simple, whether done locally via its in-built display, remotely with its onboard web server or from the console. Powered by either PoE or its USB-C port, this versatile device is at home in many different environments as a standalone interface, truss-mounted in the rig via its M12 receiver or installed via its DIN rail mount.

GeNetix Node 2 supports Art-Net, sACN, RDM and supports both DMX input or output from its two DMX ports.

Overview:

• 2 RDM DMX Ports supporting Input and Output

• Supports Art-Net & sACN

• Webserver for remote configuration

• In-built display and encoder for local configuration

• Can be USB or PoE powered

• Unlocks MagicQ PC Systems into Core Mode via either USB or Network

Hardware Specifications:

• RDM Direct DMX Ports: 2

• Network Ports: 1

• PoE Input: Yes (Port 1)

• USB Ports: 1 USB-C

• Kensington Security Lock Fixing: Yes

• Width: 125mm (4.92 inches)

• Depth: 133mm (5.23 inches)

• Height: 44mm (1.73 inches)

• Weight: 0.85 KG (1.87 lb)
