CDD15 High-Power Passive 2-Way Speaker System

The CDD15 is a high output passive loudspeaker. It is a great option that requires high sonic performance from one enclosure.

Martin's CDD passive loudspeakers are some of the best passive speakers you can get that have a built-in crossover.  Using DSP makes them even more amazing!

From The Manufacturer:

Ideal for medium-to-large rooms, the CDD15 is a very high-power, passive two-way system designed for installations that demand the ultimate in sonic performance from a single enclosure. It combines very high output capability with exceptional fidelity and coverage consistency. Its coaxial drive unit comprises a powerful 15” (380mm)/3” (75mm) voice coil LF driver and a 1.4” (35mm) exit HF compression driver with a 3” (75mm) pure titanium diaphragm.

Features:

• High-output, CDD™ passive two-way system

• Coaxial Differential Dispersion™ technology

• Elegant birch plywood enclosure

• User-rotatable coaxial drive unit

• Vertical and horizontal mounting options

• Screw-free perforated steel grille

• 8Ω nominal impedance

• Integral inserts for eyebolt suspension

• Black or white standard color options

Applications:

• Live Music Clubs and Bars

• Nightclubs

• Bars and Restaurants

• Museums and AV Spaces

• Convention Centres

• Hotels

• Retail Outlets

• Leisure Centres

• Houses of Worship

Specifications:

• Type

• High-output, Coaxial Differential Dispersion passive two-way system

• Frequency Response

• 55Hz-18kHz ± 3dB, -10dB @ 45Hz

• Driver

• LF: 15” (380mm)/3” (75mm) voice coil, long excursion, shared ferrite motor system with HF

• HF: 1.4” (36mm) exit/3” (75mm) voice coil, titanium dome compression driver

• Rated Power

• 400W AES, 1600W peak

• Sensitivity

• 100dB

• Maximum SPL

• 126dB continuous, 132dB peak

• Nominal Impedance

• 8Ω

• Dispersion (-6dB)

• 100˚-60˚ horizontal, 60˚ vertical (user-rotatable)

• Crossover

• 1.6kHz passive

• Enclosure

• 68 liter, birch plywood

• Finish

• Black or white textured paint

• Protective Grille

• Black or white perforated steel with scrim cloth backing

• Connectors

• Low profile 20A push-lock

• Pin Connections

• Left to right: Input+, Input -, Link -, Link+

• Fittings

• 10 x M8 fly points

• Dimensions

• (W) 432mm x (H) 685mm x (D) 413mm

• (W) 17.01ins x (H) 26.97ins x (D) 16.26ins

• Weight

• 26kg (57.32lbs)
