AF-5X High Powered Special Effects Fan

The Antari AF-6 is a high-powered professional special effects fan designed to amplify fog, haze, snow, foam, bubble and confetti effects. Producing up to 2,583 CFM of airflow, the AF-6 offers powerful wind output, flexible 180° positioning, DMX512 control, timer operation and optional wired or wireless remote control for professional stage and entertainment applications.

From The Manufacturer:

Step up to the AF-6 – bigger and more powerful than ever. This fan is designed to blow your audience away with its increased wind power, making your effects more dynamic and impressive. Elevate your performances with more wind, more effects, and more awesomeness. It’s a game-changer!

Key Features:

• High-powered professional special effects fan

• Up to 2,583 CFM airflow

• Up to 1,550 RPM fan speed

• 180° adjustable positioning

• LED display with tactile buttons

• Manual control

• Timer control

• DMX512 control

• 1 DMX channel

• Optional wireless control

• Optional wired remote control

• Neutrik powerCON TRUE1 power connection

• 5-pin XLR DMX connection

• 4-pin XLR remote connection

• Suitable for use with multiple atmospheric and special effects

• Rugged professional construction

Specifications:

• Product Type: High-Powered Special Effects Fan

• Manufacturer: Antari

• Model / SKU: AF-6

• Rated Power: 250 W

• Airflow @ 120 V / 60 Hz: 2,583 CFM

• Airflow @ 240 V / 60 Hz: 2,550 CFM

• Fan Speed @ 120 V / 60 Hz: 1,550 RPM

• Fan Speed @ 240 V / 60 Hz: 1,530 RPM

• Maximum Noise Level: 81.5 dB

• Adjustment: 180°

• Control Methods: Manual / Timer / DMX512 / Optional Wireless / Optional Cable Remote

• DMX Channels: 1

• Power Connection: Neutrik powerCON TRUE1

• DMX Connection: 5-Pin XLR

• Remote Connection: 4-Pin XLR

Applications:

• Fog distribution

• Haze distribution

• Snow effects

• Foam effects

• Bubble effects

• Confetti effects

• Concerts

• Touring productions

• Theatre

• Film and television

• Theme parks

• Live events

• Professional special effects

Included Accessories:

• No additional accessories specified by Antari

Accessories (Not Included):

• Antari SC-2 Cable Remote

• Antari WTR-20 Wireless Module

• DMX cable

• Safety cable

• Mounting hardware as required

Size:

• 461 × 623 × 614 mm

• 18.20 × 24.53 × 24.17 in

Weight:

• 22.3 kg

• 49.1 lb

Electrical / Thermal:

• US Input Voltage: AC 100–120 V, 50/60 Hz, 2.5 A

• EU Input Voltage: AC 220–240 V, 50/60 Hz, 1.5 A

• Rated Power: 250 W

• Ambient Operating Temperature: 0°C–40°C

• Maximum Noise Level: 81.5 dB
