A premium 8-inch coaxial in-ceiling loudspeaker designed for medium to high-volume commercial audio applications, delivering powerful full-range sound, high sensitivity, and flexible operation in both low-impedance and distributed audio systems

Manufacturer Description

The JBL Control 18C/T is a full-range ceiling speaker consisting of a 200 mm (8.0 inch) high-tech cone driver and a 25 mm soft-dome liquid-cooled tweeter, mounted in a vented, paintable baffle with an integrated backcan for quick and easy installation. It is designed to provide excellent sound quality for a wide variety of medium to high-volume applications such as retail stores, airports, lounges, hotels, educational facilities, and music/paging systems.

Features

• 200 mm (8") high-output polypropylene cone woofer with butyl rubber surround

• 25 mm (1") soft-dome liquid-cooled tweeter

• Integrated blind-mount backcan for simplified installation

• Combined 70V / 100V transformer and 8Ω direct operation

• 90W low-impedance operation / 60W multi-tap distributed operation

• 90° conical coverage pattern for consistent room coverage

• High 92 dB sensitivity for strong output with efficient amplifier power

• Dual conduit / cable clamps for clean cable management

• Available in White or Black (-BK) finishes

• Suitable for foreground music, background music, and paging systems

Specifications (List Format)

• System Type: 2-way coaxial in-ceiling loudspeaker

• LF Driver: 200 mm (8") high-output driver

• HF Driver: 25 mm (1") soft-dome liquid-cooled tweeter

• Frequency Range (-10 dB): 58 Hz – 20 kHz

• Frequency Response (±3 dB): 80 Hz – 16 kHz

• Power Rating:

• 180 W continuous program

• 90 W continuous pink noise

• 360 W peak

• Maximum Input Voltage: 31.8 V RMS / 63.6 V peak

• Sensitivity: 92 dB

• Coverage Angle: 90° conical

• Maximum SPL:

• 112 dB continuous

• 118 dB peak

• Nominal Impedance: 8 ohms

• Transformer Taps:

• 60 W / 30 W / 15 W @ 70V / 100V

• 7.5 W @ 70V only

• Input Connector: Removable locking 4-pin connector

• Materials:

• ABS baffle (UL94-V0 / UL94-5VB fire rated)

• Zinc-plated steel backcan

• Ceiling Cutout Size: 282 mm diameter

• Dimensions: 307 mm diameter × 274 mm depth

• Net Weight: 6.4 kg

• Plenum Rated: Yes (UL1480 / UL2043 compliant)

 Included Items

• 1 × JBL Control 18C/T speaker

• Integrated steel backcan

• C-ring support backing plate

• 2 × tile support rails

• Cutout template

• Paint shield

• Removable locking multi-pin connector

• Grille with safety tether
