Sku:
JOL299
Jolt Panel FX2
Regular price
$1,049.99
Regular price
Sale price
$1,049.99
Unit price
per
Shipping calculated at checkout.
Vendor: ADJ
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
From the Manufacturer
The ADJ Jolt Panel FX2 provides lighting designers with the creative potential of generating strikingly bright white strobe flashes, vibrant color washes, and animated ‘eye candy’ chase effects ideal for concert productions, festival stages and rental houses, as well as for permanent installation in large nightclubs.
Features
Light Source:
- 800 x 0.5W RGB SMD LEDs + 48 x 5W Cool White SMD LEDs
- 73° Beam Angle
- 111° Field Angle
- Color Temperature: Red: 620-630nm. Green: 515-525nm. Blue: 460-470nm. / Cool White: 6900-7400K
- CRI: 69.4
- 50,000 Hour Average LED Life
Features:
- 40 x RGB LED zones
- 6 x Cool White LED zones
- 25 built-in RGB LED Program Macros
- 9 built-in Cool White LED Program Macros
Control:
- Control Protocol: DMX, Aria X2 and RDM
- 10 DMX Modes: 6, 9, 13, 18, 36, 41, 51, 81, 126 and 141 channel modes
- Dim Modes: 6 Presets (Standard, Stage, TV, Architectural, Theatre & Stage 2)
- Dim Curves: 4 Presets (Linear, Square Law, Inv Square Law and S Curve)
- 0-100% Smooth Dimming
- Strobe, shutter & pulse control
- Max Strobe Rate 20Hz. Min Strobe Rate: 1Hz.
- With Wired Digital Communication Network
- Display: OLED display with 4-button touch menu
Connections:
- Data: IP20 Indoor locking 5-pin DMX In/Out
- Power: IP20 Indoor locking power In/Out
Electrical:
- 100-240V 50Hz/60Hz (Auto Sensing)
- Max Power Consumption: 214W @120V., 208W @230V.
- Max Power Link: 6pcs @120V., 12pcs @230V.+
- Fuse Protected: T5A/250V Glass Fuse (5*20MM)
Dimensions / Weight:
- Length: 5.28" (134.2mm)
- Width: 16.42” (417mm)
- Height: 10.26” (260.5mm)
- Weight: 13.67 lbs. (6.2 kg)
What’s Included:
- 1x 6ft (1.83m) Indoor Power locking to Edison power cable (U.S.)
- 1x Frost Filter
Optional Accessories:
- 180mm Omega Bracket
- JPFXBLKF (Black Filter)
- JPFXLINF (Linear Effect Filter)
Approvals and Ratings:
- CE
- cETLus (Pending)
- IP20
Tech Specs
View full details
