Laser Ray 13 RGB IP65 2-Pack w/ Case

The Unity LaserRay 13 RGB (IP65) is a professional multi-head laser array with XY scanning technology housed in a weatherproof IP65 enclosure, designed for stadiums, arenas, theaters, mega clubs, and outdoor shows.

From the Manufacturer

The LaserRay 13 RGB (IP65) is a powerful multi-head laser array equipped with high-speed XY scanning technology, built inside a weatherproof IP65 housing made for life on the road. Designed for lighting professionals working on stadiums, theaters, mega clubs, and small to medium outdoor shows, the LaserRay 13 delivers breathtaking, impactful visual experiences wherever the show takes you.

With integrated DMX control hardware and a 210-channel profile assignment (35 channels per head), control is a breeze. You can set up, design, and control the LaserRay 13 from the lighting console of your choice — whether you're using it as a standalone rig or adding it to your existing laser setup.

*The LaserRay 13 is sold as a pack of 2 units, housed together in a single rolling flight case along with all accessories.

Features

• Full-color laser bar with six independent heads and high-speed XY scanning for dynamic beam and graphic output
• Weatherproof IP65-rated housing engineered for touring, outdoor, and demanding live event environments
• 210-channel DMX profile (35 channels per head) for comprehensive lighting console control
• Compatible with any standard DMX lighting console — no proprietary software required
• 30,000 points per second scanning system for crisp, detailed laser output
• Analog 100kHz modulation for precise color and intensity control
• Wide operating temperature range of -10°C to 45°C for reliable performance in any climate
• Sold as a pack of 2 units in a single heavy-duty rolling flight case
• Comprehensive laser safety features including keyed interlock, emission delay, internal/case interlock, scan-fail safety, mechanical shutter, and adjustable aperture masking plate
• Fully complies with EN 60825-1 and FDA laser safety regulations
• Recommended use: Stadiums, arenas, mega clubs, theaters, houses of worship, small and medium outdoor shows

Specifications

Laser

• Type of Laser: Full-color laser bar, semiconductor diode laser system with XY scanning and six independent heads
• Guaranteed Optical Output: >13,200mW
• R | G | B Output (per head): 600mW | 800mW | 800mW
• R | G | B Wavelength: 638nm | 525nm | 445nm
• Beam Size: 3mm x 3mm
• Beam Divergence: <1.4mrad (full angle)
• Modulation: Analog 100kHz

Control

• Control Signal: DMX (35-channel assignment per head, 210 channels total)
• System Features: Adjustments via DMX for safety, zones, geometric correction, and colors

Scanning

• Scanning System: 30,000 points per second @ 8°
• Scan Angle: 45°

Power & Environment

• Power Requirements: 100–240V / 50–60Hz
• Max Power Consumption: 600W
• Operation Temperature: -10°C to 45°C
• Ingress Rating: IP65

Physical

• Weight: 24kg (per unit)
• Dimensions per bar (L x W x H): 998mm x 222mm x 148mm

Safety

• Safety Compliance: EN 60825-1 and FDA regulations
• Laser Safety Features: Keyed interlock, emission delay, internal/case interlock, scan-fail safety, mechanical shutter, adjustable aperture masking plate

What's in the Box

• LaserRay 13 RGB (XY-IP65) laser system (x2)
• Heavy-duty rolling flight case
• E-stop box
• E-stop cable (10M / 30ft)
• DMX cable (10M / 30ft)
• Power cable (1.5M / 4.5ft)
• Safety interlock
• Safety keys
• Manual
• Quick start guide
• Variance card
• *Service dongle (included for units shipped outside the US)
