MagicQ Stadium Connect

The MagicQ Stadium Connect is powerful lighting console for those looking for a portable solution. It has the same faders and keyset as their larger consoles giving you similar capabilities. This can be a great option for medium to large events  that require a portable solution.

From the Manufacturer:

MagicQ Stadium Connect is a PC-based programming interface with the same programming keyset and dual crossfaders as the MQ250M and MQ500M. Outputting 64 universes directly from the Connect, and the ability to pre-vis up to 256 universes, MagicQ Stadium Connect is the ultimate solution for complete control on-the-go. With 10 backlit and motorised faders and 10 backlit playback encoders with executors, the MagicQ Stadium Connect provides plenty of programmable real estate for your show.

Overview:

• 10 fully motorised fader playbacks

• 10 encoder playbacks

• RGB illumination of playbacks

• Backlit buttons

• 64 universes direct from MagicQ for Art-net/sACN output

• 256 visualisation universes for pre-programming

• Network port acts as network interface for PC

• Dual 100mm Manual Cross Faders

• 2 dedicated high power USBs for charging of phones/tablets

Hardware Specifications:

• Direct DMX Outputs: 4

• Motorised Playbacks: 10

• Encoder Playbacks: 10

• Total no of Playbacks: 20 (10+10)

• Dual Cross Faders: Yes

• Attribute Encoders: 4

• Backlit Keys: Yes

• Illuminated Playback/Encoders with RGB control: Yes

• Intensity Wheel: 1

• Network Ports: 1

• USB Ports : 4

• Audio Input Sound to Light: Yes

• MIDI Ports 1 in and out: Yes

• LTC Timecode Ports in and out: Yes

• 10Scene Port: 1

• Power Input, Neutrik powerCON TRUE1 110 to 240 VAC

• Width: 761mm (29.9″)

• Depth: 467mm(18.3″)

• Height: 197mm (7.7″)

• Weight (stadium connect in flightcase): 20.0kg (44.1lbs)
