Magma Fog 1500 IP-II

Magma Fog 1500 IP MK II is a water based fog machine that

From The Manufacturer:

The MAGMA FOG 1500 IP-II™ is a 1700W water based, IP67 rated fog machine with a maximum output of 60,000 CFM (cu ft/min). Features include an easy-to-use onboard LCD touch screen, an intuitive DMX-512 and RDM control, and optional wired and wireless remote-control. Each MAGMA FOG 1500 IP-II comes equipped with a thermally protected heat exchanger that has an initial warm up time of 14 minutes, with a fluid consumption rate of 6.76 oz (200 ml/min). This unit is designed with a durable aluminum housing, IP65 locking power in, IP65 locking 5pin XLR connectors (DMX In/Out), a 5-liter (1.32 gallon) tank, two heavy duty carry handles, and a hanging bracket for truss mounting

Features:

• 1700W IP67 water-based fogger

• 60,000 CFM (cu ft/min) maximum output

• Thermally protected heat exchanger

• Intuitive DMX-512 and RDM control

• Onboard LCD touchscreen

• Optional wireless and wired remotes

Specifications:

• Performance

• Rated Power: 1700W

• Max Output: 60,000 CFM* (cu ft/min.)

• Ready Time: Initial = 14 Minutes*

• Fluid Capacity: 1.32 gallons (5 liters)

• Fluid Consumption: 6.76 oz/min (200 ml/min)

• *approximate

• Compatible Fluid

• Atmosity Extreme Filtered Fog Fluid (AEF-2L, AEF-4L, AEF-20L)

• Construction

• Thermally Protected Heat Exchanger

• Rugged Case Design

• Convenient Carry Handles

• Control

• 3 DMX Channel Modes (1 / 2 / 4)

• Onboard LCD Touch Control Panel

• DMX-512 and RDM Protocol Support

• Optional MAGFLY Wireless DMX Transceiver

• Optional MAGRF Wireless and MAGREMOTE Wired Remotes

• Connections

• Locking 5pin XLR Connector, DMX In/Out

• IP67 Locking Power Connector In

• With Wired Digital Communication Network

• Size / Weight

• Length: 25.5 in. (648mm)

• Width: 14.6 in. (372mm)

• Height: 16.2 in. (411mm)

• Weight: 74.3 lbs. (33.7kg)

• Electrical

• AC120V 60Hz (US Version)

• AC230V 50Hz (EU Version)

• 20A @ 120VAC(NFB)

• 10A @ 230VAC - 240VAC

• Max Power Consumption: 1700W

• Thermal

• Maximum Ambient Temperature (Ta max) 104°F (40°C)

• Exterior Surface Temperature, Steady State: 149°F (65°C)

• Accessories

• MagFLY (MSR934) Wireless DMX Transceiver Module

• MagRF (MSR912) RF Module and Wireless Remote

• Approvals / Ratings

• CE | IP67 | RoHS | UKCA
