NET 4

The NET 4  is a DMX over Ethernet node. It can be truss mounted and is easy to configure with the LED display.

From the Manufacturer:

NET 4 is a versatile 4-port DMX over Ethernet node that can be truss mounted with M10 or M12 threads or rack mounted using the optional Aria X2 shelf. It is compatible with DMX-512, RDM, Artnet and sACN protocols, ensuring a broad spectrum of integration possibilities. The 1.7-inch LED display facilitates easy configuration, allowing you to fine-tune settings and monitor status at a glance.

Features:

• ArtNet / sACN /DMX, 4 Port Node

• Line Voltage or Power over Ethernet (PoE) powered

• DHCP or Static IP Address

• 1.7”LCD Display

• Configurable from unit menu or web browser

Specifications:

• Protocols

• DMX512

• RDM

• Artnet

• sACN

• Physical

• M10 & M12 Threads for rigging

• Safety eyelet

• 2x Indoor RJ45 Input & Output

• 4x 5pin XLR Input / Output

• Dimensions & Weight

• Length: 5.93" (150.5mm)

• Width: 8.48" (215.3mm)

• Height: 1.66" (42mm)

• Weight: 3.16lbs. (1.43kg)

• Power

• AC Input 95-240V,50/60Hz

• PoE 802.3af

• AC Power: 15W

• PoE Power: 15W

• Power Consumption: 3.7W @ 120V and 4W @ 230V

• Power Input Protection: Fuse, T1.25A/250 (5.2x20mm)

• Thermal

• Ambient Operating Temperature: -4°F to 113°F (-20°C to 45°C)

• Humidity: <75%

• Storage Temperature: 77°F (25°C)

• Certifications & Qualifications

• CE

• cETLus (Pending)

• FCC

• IP20

What’s Included?

• Outdoor locking power cord

Optional Accessories:

• Aria X2 Shelf

• 35mm Din Rail adapter (2pcs. Required)
