NET 8

The NET 8 is a DMX over Ethernet node. It can be mounted in a 19-inch rack case and is easy to configure with the LED display.

From the Manufacturer:

ADJ’s NET 8 is a versatile 4-port DMX over Ethernet node that can be mounted in a 19-inch rack case. It is compatible with DMX-512, RDM, Artnet and sACN protocols, ensuring a broad spectrum of integration possibilities. The 1.7-inch LED display facilitates easy configuration, allowing you to fine-tune settings and monitor status at a glance.

Features:

• ArtNet / sACN /DMX, 8 Port Node

• Line Voltage or Power over Ethernet (PoE) powered

• DHCP or Static IP Address

• 1.7”LCD Display

• Configurable from unit menu or web browser

Specifications:

• Protocols

• DMX512

• RDM

• Artnet

• sACN

• Connections

• 2x Indoor RJ45 Input & Output

• 8x 5 pin XLR Input / Output

• Dimensions & Weight

• Length: 5.09" (129.3mm)

• Width: 19" (482.5mm)

• Height: 1.73" (43.8mm)

• Weight: 4.76lbs. (2.16kg)

• Power

• AC Input 95-240V,50/60Hz

• PoE 802.3af

• AC Power: 15W

• PoE Power: 15W

• Power Consumption: 5.7W @ 120V and 5.9W @ 230V

• Power Input Protection: Fuse, T1.25A/250V (5.2x20mm)

• Thermal

• Ambient Operating Temperature: -4°F to 113°F (-20°C to 45°C)

• Humidity: <75%

• Storage Temperature: 77°F (25°C)

• Certifications & IP Rating

• CE

• cETLus (Pending)

• FCC

• IP20

What’s Included?

• Indoor locking power cord
