Sku:
NX2984
Onyx NX2
- Regular price
- $8,390.00
- Regular price
-
- Sale price
- $8,390.00
- Unit price
- per
Shipping calculated at checkout.
Vendor: OBSIDIAN Control Systems
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
Compact, quick to setup and powerful - that's the NX2!
From the Manufacturer:
The NX2 is the ultimate compact yet powerful fully integrated lighting controller. As a member of the innovative ONYX platform from Obsidian Control Systems the NX2 is feature rich and never restricted in its capabilities. NX2 includes a high-brightness full HD multi-touch screen; 8 assignable parameter encoders; an assistive mini touch-screen; full keypad and command section; a dedicated grandmaster and 10 full playbacks with four freely assignable buttons.
The NX2 is ergonomic with its compact footprint, full ONYX command and keypad section and the bright adjustable HD touch screen. It is always ready to run the largest shows and events at a moments notice.
With four DMX ports, Timecode, Midi and dual Gigabit ports for up to 64 Universes of Art-Net, sACN plus the ONYX X-Net protocol the NX 2 has all the connectivity and power the ever-increasing sizes of shows demand. Two additional 4K touch monitors are supported for even more direct access at anytime.
From the GEAR Pro's:
As you probably know, ONYX is my favorite console for a variety of reasons. The NX2 is their console that fits well for a lot of basic to complex shows. It's main limitations are the fact that the faders are not motorized, and you just don't get as many playbacks as an NX4.
But, it's a really solid, reliable console that allows you to do a LOT. And if you miss those faders on the side - add an NX Touch - that'll get you half way there while still keeping your setup compact!
Video Review:
In the Box:
- (1) Obsidian NX2
- (1) RGB LED desk lamp, angular XLR connector, 13"
- (1) Obsidian USB Cable
- (1) Dust Cover
- (1) External PSU (12V 11A)
- (1) 1.5 m power cable, 3pin IEC
- (1) USB 3.0 Recovery stick
- (1) CAPTURE Visualizer SOLO License
Features:
- Portable and compact fully featured lighting console
- Adjustable 15.6” Full HD multi touch screen, 2x external 4K Touch Displays
- ONYX Premier License (64 Universes)
- Fully integrated processing
- 10 Playbacks, 8 Encoders, Keypad and internal 3.5" touchscreen
- Network, DMX, Timecode, and Midi Connectivity
- CAPTURE Solo Edition License
Tech Specs
Control
DMX 3-Pin Connectors?: No
DMX 5-Pin Connectors?: Yes
Physical:
Length: 11.9 in
Width: 21.3 in
Height: 4.8 in
Weight: 19.8 lb
Electrical
Voltage Range: 100 - 240 VAC 50/60Hz
Maximum Wattage: 132w
Power Cable Connector - Fixture Side: 4 Pin XLR
Main Power Connector on Included Cable: Edison
Power Cable Length: 1.5 m
