Sku: NXW888

ONYX NXW

$3,249.00

Sold out

Shipping calculated at checkout.

Vendor: OBSIDIAN Control Systems

This item is in stock and ready to ship. Typical processing time is one business day.

Condition: New New

Quantity

Description

Is it the best value in console wings? The ONYX NXW is the first of the next generation of ONYX consoles - a PC wing with motorized, backlit faders, full RGB backlight, expandable universe count via an internal key, and more!

From the Manufacturer:

KEY FEATURES
Fully featured control surface, portable and lightweight
10 Motorized Playbacks
10 Multi-Function Keys
4 Encoders
Full-color backlit faders, encoders, and high-precision optical key switches
Main Playback controls with Go and Pause/Back
Numeric Keypad
16 Universe License for ONYX included (expandable up to 128 with ONYX Keys)
Plug and Play USB device for any PC with ONYX
Magnetically attaches to NX P and NX1
Internal PSU

SPECIFICATIONS: SURFACE

10 x 60 mm motorized playback faders, each with 4 x function-assignable backlit buttons
10 x customizable backlit multi-function keys
Backlit playback Select button
Backlit Main Go section with Go, Pause, Snap and Release
4 x digital rotary encoders with push function and status backlighting for fixture parameter control
Backlit numerical keypad and command keys
OLED Bank status display
USB-C port

CONNECTIONS

IP65 Locking Power In
IP65 Locking Power Out, ideal for NX P
USB-C in and out
ONYX License Key Expansion Port
Gigabit Locking RJ45 Ethernet adapter
4 x locking 5-pin XLR sockets, for DMX/RDM Out, and DMX In
4-pin XLR for Desk Light
Kensington Lock

PHYSICAL

Length: 300 mm
Width: 532 mm
Height: 82 mm
Weight: 6 kg

ELECTRICAL

100-240V nominal, 50/60 Hz

INCLUDED ITEMS

RGB LED desk lamp, angular XLR connector
Dust Cover
Obsidian USB-C Cable
IP65 locking power cable

From the GEAR Pro's:

Where do we begin? Simply put, the ONYX NXW is a big step forward for the ONYX consoles - it's the first piece of hardware in a new generation, and a significant upgrade for most users from the NX Wing.

What's new? They essentially have taken all of the feedback from users over the past 15+ years and rebuilt the hardware from scratch, carrying over design features from the NX1 like the True1 power input (with thruput on the NXW) and magnetic console attachment for connection to the NX1, K, P, and future hardware like the NX3.

New features include quieter, color-backlit faders, customizable backlit keys, completely redesigned keys which include a different sensitivity on programming (light/shallow) vs playback (long/heavier).

The NXW comes with a 16 universe ONYX license, which can be upgraded via an internal key, and also offers a ethernet port for any connected PC. It also can connect to ONYX consoles as a wing, which the NX Wing could not do.

For the full details, check out the videos below:

Tech Specs

Control

DMX 5-Pin Connectors?: Yes

Physical:

Length: 11.9 in

Width: 21.3 in

Height: 3.9 in

Weight: 10.2 lb

Electrical

Voltage Range: 100 - 240 VAC 50/60Hz

Maximum Wattage: 132w

Power Cable Connector - Fixture Side: 4 Pin XLR

Main Power Connector on Included Cable: Edison

Power Cable Length: 1.5 m

View full details

ONYX NXW
