P3 PowerPort 1000 IP Install

The P3 PowerPort 1000 IP Install is a multifunctional power and data processor tailored for Martin's creative LED video products like Exterior PixLine™ and VC-Dots™. It seamlessly integrates power supply and high-speed video processing, offering easy setup, flexible indoor or outdoor placement, and optional fiber interface for enhanced connectivity, making it ideal for permanent outdoor installations.

From The Manufacturer:

The P3 PowerPort 1000 IP Install is an integrated power supply and data processor for Martin’s range of creative LED video products, including the Exterior PixLine™ and VC-Dots™. When driven by one of Martin’s award-winning P3™ System Controllers™, it combines stable power delivery with high-speed, high-capacity video processing. Setup and configuration are easy and intuitive. A full outdoor rating and optional fiber interface make the product perfect for permanent outdoor installations.

• Power and data processor for all Martin’s fixed-installation creative LED video products
• Flexible integration: can be located remotely, indoors or outdoors
• Easy cabling and configuration

Features:

• P3 image processing technology
• Set-up and addressing via P3 System Controller family
• No local configuration needed
• P3 input and thru to allow daisy-chaining
• Optional fiber-interface
• 4 hybrid power/data output ports
• Wall-mountable or free-standing
• Can be located up to 50 m away from the creative LED video products
• IP66

Physical:

• Length: 426 mm (16.8 in.)
• Width: 483 mm (19.1 in.)
• Height: 146 mm (5.8 in.)
• Weight: 8 kg (17.7 lbs.)

Electrical:

• AC power: 120-277 V nominal, 50/60 Hz
• Power supply unit: Auto-ranging electronic switch-mode
• Typical total power consumption: 1000 W (including full load of connected display devices, all at full intensity)
• Typical half-cycle RMS inrush current: 20.9 A
• Total power consumption in idle state (at 25° C, all connected devices powered off): 22 W
