PCC130

The AKG PCC130 is a low profile boundary layer microphone, designed to sit unobtrusively on a table and pick up voices even from a distance.

From the Manufacturer:

The PCC130 and the PCC130 SW are cardioid boundary layer microphones of professional quality that, due to their small size, fit perfectly on small tables. Thanks to low self-noise and very high sensitivity, the microphone picks up even distant voices clearly and naturally. A bass-tilt switch allows the user to tailor the low-end response and reduce subsonic noise. The PCC130 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. A high-intensity LED lights when the unit is on. For easy installation, both microphones offer an XLR connector and a detachable cable.

Features:

• Cardioid polar pattern: Reduces background noise and feedback
• PCCâ {Phase Coherent Cardioidâ technology): For optimum speech intelligibility
• Three-position bass-tilt switch: For optimized suppression of subsonic noise
• Silent-operating on/off switch (PCC130 SW only): To reduce the number of simultaneously open mics
• Detachable cable: Easy to install and service

Specifications:

• Audio frequency bandwidth: 50 - 20000 Hz
• Equivalent noise level: 22 dB-A
• Sensitivity: 22 mV/Pa
• Signal to Noise: 72 dB-A
• Dimensions
  • Length: 89 mm
  • Width: 64 mm
  • Height: 25 mm
• Design
  • Finish: satin black
• Audio Output
  • Type: Switchcraft TB3M
  • Gender: Male
  • Contacts: 3-pin
• Powering Interface
  • Voltage: 12 to 48 V
• Application: Conferencing
• Device: Boundary Layer Microphone
