PCC170 SWO

The AKG PCC170 SWO supercardioid boundary layer microphone is designed for use on tables or lecterns, such as conferencing or distance learning environments.

From the Manufacturer:

The PCC170 and the PCC170 SW are professional boundary layer microphones with supercardioid polar pattern to minimize background noise and feedback. The microphones are designed for use on boardroom tables or lecterns. Both microphones provide a bass-tilt switch, allowing the user to tailor the low-end response and reduce subsonic noise. The included RFI suppression ensures trouble-free operation even with active cell phones nearby. The PCC170 SW has a silent-operating programmable membrane switch that can be configured for touch on/off, momentary on or momentary off. For easy installation, both microphones offer an XLR connector and a detachable cable. The PCC170 SWO looks identical to the PCC170 SW but features a pair of extra leads in the mic cable to allow isolated remote sensing of the microphone switch closure.

Features:

• Supercardioid polar pattern reduces muddy-sounding room acoustics and
• background noise
• PCC® technology (phase coherent cardioid®) for clear and natural sound
• Programmable, silent operating on/off membrane switch
• Extra leads in mic cable allow remote sensing of mic switch closure
• Small and inconspicuous

Specifications:

• General Specifications
  • Audio frequency bandwidth: 50 - 20000 Hz
  • Equivalent noise level: 22 dB-A
  • Sensitivity: 22 mV/Pa
  • Signal to Noise: 72 dB-A
• Dimensions
  • Length: 123 mm
  • Width: 86 mm
  • Height: 23 mm
• Design
  • Finish: black
• Audio Output
  • Type: Switchcraft TB3M
  • Gender: Male
  • Contacts: 3-pin
• Powering Interface
  • Voltage: 12 to 48 V
• Application: Conferencing
• Device: Boundary Layer Microphone
