Sku:
PMD003
PM-DMX1 Pan Motor for Crisp Max
- Regular price
- $400.00
- Regular price
-
- Sale price
- $400.00
- Unit price
- / per
Vendor: Magmatic
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
This pan motor allows you to move the snowfall from an Elation Magmatic Crisp Max™ snow machine.
From the Manufacturer:
Magmatic PM-DMX1™ is an optional pan motor accessory for the Magmatic Crisp Max™ Snow Machine. Install the output nozzle of the Crisp Max, using the included mounting bracket, onto the PM-DMX1 to precisely control 120 degrees of pan movement via DMX-512 or manually using the 4-button LED control panel menu display on the unit.
The PM-DMX1 features 2 DMX channel modes, 0-120 degree position index movement and 3 different degree internal auto-pan programs (60°, 90°, 120°) each having 5 speed settings, a pan inversion mode which inverts the pan movement, primary / secondary modes, 5pin DMX in/out for easy control connection and linking multiple units, an included mounting bracket that better balances weight distribution of the Crisp Max nozzle unit, mini-omega bracket so PM-DMX1 can be clamped and /truss mounted, and a 100-240V auto switching power supply.
In the Box:
- (1) PM-DMX1
- (1) Locking Power Cable
- (1) Nozzle Bracket
Features:
- 120 Degrees of Pan Movement
- Manual and DMX-512 Control
- 2 DMX Channel Modes
- Primary/Secondary Modes
- 60°, 90°, 120° Auto-Pan Programs
- 5 Auto-Pan Program Speeds
- Pan Inversion Mode
- Holds up to 35lbs.
- Includes Mounting Bracket for Crisp Max Nozzle
- Includes Omega Bracket for clamp / truss mounting
Tech Specs
Control
DMX Channel Modes: 1 / 2
DMX 3-Pin Connectors?: No
DMX 5-Pin Connectors?: Yes
Physical:
Length: 5.8 in
Width: 6.4 in
Height: 14.2 in
Weight: 4 lb
Electrical
Voltage Range: 100 - 240 VAC 50/60Hz
Maximum Wattage: 11w
Power Cable Connector - Fixture Side: PowerCON
Main Power Connector on Included Cable: Edison
Warranty
Warranty: 2 Years
