PSP120
Prisma Mini Par 20
- Regular price
- $225.00
- Regular price
-
- Sale price
- $225.00
- Unit price
- per
Shipping calculated at checkout.
Vendor: Magmatic
Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!
Description
Description
*This device requires an external driver linked here.
From the Manufacturer:
PRISMA MINI PAR 20™ is an IP65 rated exterior UV wash par luminaire that produces 365nm peak true UV output with zero visible light, and an impressive 20 degree beam angle.
Powered by the PRISMA DRIVER 8™ or PRISMA DRIVER 8IP™, features include an adjustable mounting yoke, a durable aluminum housing, and a 9 ft (2.7m) 2-Conductor 14 Gauge IP rated power/data pigtail cable.
Powered by the PRISMA DRIVER 8™ or PRISMA DRIVER 8IP™, features include an adjustable mounting yoke, a durable aluminum housing, and a 9 ft (2.7m) 2-Conductor 14 Gauge IP rated power/data pigtail cable.
In the Box:
- (1) Prisma Par 20
- (1) Phoenix Connector
Features:
- Light Source: 7x 3W UV LEDs
- Beam Angle: 20°
- Wavelength: 365nm
- Dimming: Variable Dimming Curve Modes
- Refresh Rate: Variable
- Strobe: Variable
- Control Protocol: DMX, RDM
- Operating Modes: DMX, Manual
- IP Grade: IP65
Tech Specs
Optics:
Light Source Type: UV LED
Light Source Wattage: 7x 3w
Minimum Beam Angle: 20.0°
Maximum Beam Angle: 20.0°
DMX 3-Pin Connectors?: No
DMX 5-Pin Connectors?: No
Physical:
Length: 5.66 in
Width: 2.66 in
Height: 5.64 in
Weight: 1.98 lb
Electrical
Voltage Range: 36.7 VDC
Maximum Wattage: 19w
Main Power Connector on Included Cable: Pigtail
Warranty
Warranty: 2 Years
