Proteus Excalibur

Regular price
$8,100.00
Regular price
Sale price
$8,100.00
Shipping calculated at checkout.
Vendor: Elation Professional

Usually ships in 1-3 business days. Fill out a quote request and we'll check if it's backordered!

  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

Description

Caret Down

The Proteus Excalibur is the newest member in the industry leading Proteus range of IP65 automated fixtures from Elation Professional. Excalibur is the brightest IP65 fully featured beam fixture ever created with incredible light output from a surprisingly compact fixture body. Rivaling existing Xenon searchlights and sky trackers, the extremely narrow 0.8° Beam ensures the fixture cuts effortlessly through the sky and is visible at great distances. The intense beam of the Proteus Excalibur projects from the ultra-wide 260mm front Lens as a massive column of light that stuns the audience.

A wide array of gobos and prism overlays allow animating the sky, and with its incredible light intensity all CMY colors remain strong and vibrant even when fully saturated. Beam control is provided through a precise internal focus lens, providing crisp projection without optical errors. Dual variable frosts allow to soften the beam when required. A remote-controlled Expander lens allows widening the beam to approximately 3.5 degrees. The fixture is ideally suited for theme parks, cruise ships, outdoor special events, large scale shows and concerts, and any situation where a massive beam or very powerful prism and flower effects are required. With its compact size and low power consumption the Proteus Excalibur can be utilized in almost any application.


In the Box:

  • (1) Proteus Excalibur
  • (2) Omega Brackets
  • (1) IP65 Rated 5pin DMX Cable
  • (1) IP65 Rated RJ45 Cable (Fixture to Fixture Interconnect Use Only!)
  • (1) IP65 Rated Power Cable

Features:

  • Light Source: Philips MSD Platinum 500 Flex 550W Lamp
  • Color Temperature: 7,000K
  • CRI: 77+
  • Beam Angle: 0.8° (3.5° Beam Expander Lens)
  • Dimming: Mechanical
  • Strobe: Variable
  • Color: CMY Color Mixing
  • Color Wheel: 14 Dichroic Colors Including CTO and UV
  • Rotating Gobo Wheel: 8 Interchangeable Rotating / Indexing Glass Gobos
  • Static Gobo Wheel: 17 Static-Stamped Metal Gobos
  • Effects:
    • Dual Rotating Prisms and Prism Macros
    • Dual Frost Filter Hybrid Wash Effect
  • Control Protocol: DMX, RDM, Art-NET, sACN
  • Operating Modes: DMX, Manual, Auto Program
  • IP Grade: IP65



Tech Specs

Optics:

Light Source Type: Discharge Lamp

Light Source Wattage: 550w

Minimum Beam Angle: 0.8°

Maximum Beam Angle: 3.5°

Control

DMX Channel Modes: 26

DMX 3-Pin Connectors?: No

DMX 5-Pin Connectors?: Yes

Physical:

Length: 19.4 in

Width: 15.1 in

Height: 27.4 in

Weight: 108 lb

Electrical

Voltage Range: 100 - 240 VAC 50/60Hz

Maximum Wattage: 800w

Power Cable Connector - Fixture Side: PowerCON True1

Main Power Connector on Included Cable: Edison
