RDM2go

The RDM2go is a simple to use tool, that can assign addresses to your RDM-capable fixtures and can also help you play test scenes on the fly.

From the Manufacturer:

RDM2go is a multi-functional tool for working with fixtures over a DMX/RDM data line. This palm-sized controller performs a multitude of tasks including RDM functionality, DMX snapshot and test-scene record and playback, DMX input and output monitoring. RDM2go features a built-in DMX cable integrity checker, and an easy to read OLED display.

It also addresses Chauvet’s Iluminarc IP fixtures that do not have a display. The unit easily recharges via a standard micro USB jack and comes with a convenient carry pouch and DMX connector converters.

Features:

• Handheld tool for managing fixtures and systems with DMX, RDM, and Ilumicode based control

• Easily address, locate and monitor RDM capable fixtures

• Check DMX addressing, cabling, and store/playback basic snapshots

• Address and set personalities of Ilumicode based architectural fixtures

• Comes with connector adaptors, USB charging cord and belt clip pouch

Specifications:

• Dynamic Specifications

• Standalone Color Mixing: Yes

• Color Temperature Presets (Ilumicode): Yes

• Dim Modes (Ilumicode): 5

• Customizable Programs: Yes

• Recall Custom Programs: Yes

• Physical

• Dimensions: 2.76 x 1.52 x 3.92 in (70 x 39 x 100 mm)

• Exterior Color: Black

• Housing Material: Aluminum die-cast

• Weight

• 0.77 lb (0.35 kg)

• Connections

• Power Input: Micro USB-B Male

• Data Connectors: 5-pin XLR

• Cable Length (power): 3 ft (0.91 m)

• Control

• Protocol(s): DMX, RDM, Ilumicode

• DMX Channels: 1, 2, 3, 4, 5, 6 or 7

• Modes/Personalities (Ilumicode): 13 personalities (ARC 1, ARC 1+D, ARC2, ARC2+D, ARC3, ARC3+D, ARC FULL, REMOTE, SOLID, SPECIAL1, SPECIAL2, VW, VW+D)

• Battery

• Battery type: Lithium Ion

• Rechargeable: Yes

• Battery Life: 8 hours

• Battery Power: 3.7 V, 1,200 mAh

• Certifications/Qualifications

• CE

• IP Rating: IP20, dry location

What’s Included?

• RDM2go

• Carry Pouch

• 2 pc, 3- to 5-pin converters

• 5-pin male to bare wire adaptor

• USB-A Male to Micro USB-B Male (3 ft)

Required Accessories:

• DMX Cables

Optional Accessories:

• DMX Cables
