Shocker Panel FX IP

The CHAUVET DJ Shocker Panel FX IP is a rugged, IP65-rated multi-effect strobe, wash, and blinder with 16 independently controllable sections of RGB and cool white LEDs, a password-protected touch display, and built-in effect macros for effortless indoor and outdoor impact.

From the Manufacturer

Shocker Panel FX IP instantly shifts between strobe, wash, and blinder looks as easily as it moves between indoor and outdoor events. 8 sections of bright RGB color plus an intense 8-section cool white LED strip add up to endless eye candy effects from one compact IP65-rated powerhouse. Setups are fast and secure with a digital touch display for choosing dazzling built-in effect macros and setting password access, all with the press of a button. Wherever they take this rugged unit, event managers and entertainers will wow party-goers with Shocker Panel FX IP’s high output and fast transitions.

Features

• Outdoor-rated versatile blinder, wash, and strobe with compelling eye candy effect macros
• 16 controllable sections (8 RGB + 8 cool white) for creative programming flexibility
• IP65-rated housing with integrated GORE valve to prevent internal humidity build-up
• Neutrik TRUE1 power input/output connections for water-resistant power linking
• Password-protected, touch-sensitive digital display for secure setup and macro control
• Trigger built-in effect macros via display or DMX control
• Power-linking support for up to 6 units @ 120 V
• Easily transported in the optional CHS-25 VIP gear bag
• Recommended use: Outdoor events, touring, festival stages, indoor clubs and events, blinder and strobe applications

Specifications

• Light Source (RGB): 480 LEDs (tri-color), 2 W, 50,000 hours life expectancy
• Light Source (White): 32 LEDs (cool white), 1.8 W, 50,000 hours life expectancy
• Beam Angle: 119°
• Field Angle: 158°
• Illuminance: 1,131 lux @ 2 m
• Lumens: 13,626
• Strobe Rate: 0 to 20 Hz
• DMX Channels: 8, 18, 34, or 47
• DMX Connectors: 5-pin XLR
• IP Rating: IP65
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 238 W, 2 A @ 120 V, 60 Hz  |  231 W, 1 A @ 230 V, 50 Hz
• Power Linking: 6 units @ 120 V  |  11 units @ 230 V
• Cable Length: 5 ft (1.5 m)
• Dimensions: 12.9 x 5.1 x 6.8 in (330 x 130 x 173 mm)
• Weight: 10.4 lb (4.7 kg)
• Startup Temperature: −4°F to 113°F (−20°C to 45°C)
• Operating Temperature: −22°F to 113°F (−30°C to 45°C)
• Approvals: CE, RoHS, MET

What's in the Box

• Shocker Panel FX IP
• Power cable
• Quick Reference Guide
