SX218-W-MAR Subwoofer

The SX218-W-MAR is a marine grade version of the SX218 subwoofer. It is a great outdoor option for medium to large events.

(White Only)

From the Manufacturer:

The SX218 delivers very high output levels and superb transient performance with minimal distortion.

Features:

• Dual-driver, direct radiating subwoofer

• 2 x 18” (460mm)/4” (100mm) voice coil, long excursion, ferrite magnet, waterproof cone

• Very high output capability

• Tour-grade plywood enclosure with flying inserts

Applications:

• Touring sound reinforcement for small and medium-size venues

• Fixed installations in concert halls, theatres, ballrooms and HoW

• Sports stadium, arena installations & corporate AV events

• Outdoor restaurant, bar and hotel entertainment areas

• Concourses and Theme Parks

Specifications:

• Type

• Dual-driver, direct radiating subwoofer

• Frequency Response

• 35Hz – 150Hz ±3dB,

• -10dB @ 30Hz

• Driver

• 2 x 18” (460mm)/4” (100mm) voice coil, long excursion, ferrite magnet, waterproof cone

• Rated Power

• 2000W AES, 8000W peak

• Sensitivity

• 105dB

• Maximum SPL

• 144dB

• Nominal Impedance

• 2 x 8Ω

• Dispersion (-6dB)

• Omnidirectional/or Cardioid (paired)

• Enclosure

• Multi-laminate birch/poplar ply

• Finish

• Durable Polyurea Coating

• Protective Grille

• Black perforated Zintec

• Connectors

• 2 x NL4 type

• Pin Connections (Input)

• LF1: 1+, 1- LF2: 2+, 2-

• Pin Connections (Link)

• LF1: 1+, 1- LF2: 2+, 2-

• Fittings

• Two skids on base, with mating channels on top

• 24 x M10 mounting points

• 4 x bar handles, 2 on each side

• 4 x fittings for optional transit cover

• M20 Pole mount insert

• 16 x M8 inserts for optional castors

• Dimensions (INCL Skids)

• (W) 1093mm x (H) 537mm x (D) 792mm

• (920mm including castors)

• (W) 43in x (H) 21.1in x (D) 31.2in

• (36.2in including castors)

• Weight

• 98.5kg (217lbs) w/o castors

• 102kg (225lbs) with castors
