TETRA DRIVER 4

The Mega-Lite Tetra Driver 4 has 4 RJ45 outputs to control the Light Pipe or Tetra Series units, with multiple mounting points for easy installation.

From the Manufacturer:

Designed to seamlessly control our Light Pipe and Tetra Series units, this all-in-one solution has 4 outputs that can be individually addressed within your preferred channel mode. To further enhance versatility, this powerful driver features multiple mounting points, allowing for easy wall mounting and clamp mounting. For easy production and installation implementation.

Features:

• Four 96W Outputs: The unit is equipped with four 96W outputs. Each port can connect up to 96W of power. When using our Light Pipe series you can create many different combinations of lengths.
• Wireless DMX: Using this function allows you to wirelessly control your DMX connected fixtures using a wireless DMX Connection.
• IP 65: Resistant to water and protected from dust, this unit is perfect for outdoor venues and event

Specifications:

Mechanical Specifications:

• IP Rating: 65
• Housing: Aluminum Extrusion
• Fastening System: M10 Clamp Mount Thread, Mounting Holes, Accessory DIN Rail Mounts
• Power Connection: Seetronics SAC3FX IP-Rated Connection (Nema 5-15 Cable Included)
• DMX Connection: 5-Pin XLR In and Out
• Wireless DMX Connection: Lumen Radio Wireless DMX Connection Receiver
• Output Connection: Four (4) RJ45 Outputs

Electrical Specifications:

• Output Ports: Four (4)
• Power Per Port: 96W
• Drive Method: Constant Voltage
• Power Consumption: 3.18 Amps, 376 Watts
• Power Supply: Electronic: Mean Well UHP-500-24
• Output: 24V DC
• Working Ambient Temp: 24 °F - 148 °F
• Cooling: Internal Fan
• Refresh: 4,000Hz
• Power Input: 90-264V AC 50/60Hz

Control and Programming:

• Control Protocols: DMX 512
• Operating Mode: 17 Pre-Programs, Manual Settings Via Display
• DMX 5 Modes:
  • 1 Channel Mode: Dimmer
  • 2 Channel Mode: Warm White, Cool White
  • 3 Channel Mode: R,G,B
  • 4 Channel Mode: R, G, B, W
  • 7 Channel Mode: Dimmer, R, G, B, W, Strobe, Macro

Size & Weight:

• Fixture Size: 13.25” X 9.5” X 4.12”
• Fixture Weight: 8.8 lbs
• Packaged Size: 14.75” x 12” x 6.75”
• Packaged Weight: 9.8 lbs
