Triton T-2

The X-Laser Triton T-2 is a production-grade laser fixture. It is IP64 rated and is a great option for those looking for a compact and versatile laser fixture, to use on small to medium sized stages and holiday displays outdoors.

From the Manufacturer:

The X-Laser Triton T-2 and Triton T-5 are the first production-grade laser fixtures engineered for IP64 durability and built in the United States.

The T-2 (2W, 2,000mW) and T-5 (5W, 5,000mW) offer moderate power at a strong value, making them ideal for creating arrays of multiple systems inline with traditional moving lights.

Specifically, these fixtures boast a compact form factor (approx. 13” x 7” x 5”, ~20 lbs) and a unique mounting solution that allows rapid deployment and IP64 durability when rigged both vertically and horizontally. The Triton T-2 and Triton T-5 have full RGB direct-injection laser diode modules, tuned for ideal balance so they can color mix on par with—or better than—today’s top-brand “traditional” fixtures. Creating looks with rich berry, vivid orange or intense lime colors is no problem for Triton.

Designers also benefit from the creative power and flexibility of X-Laser’s Mercury Laser Control System, which enables programming directly from the lighting console using the same show file and common signal protocols such as DMX, sACN, Art-Net as well as RDM configuration capability.

Designers using the Triton T-2 and Triton T-5 also benefit from laser-specific advantages such as an incredible zoom range of 0.1º to 45º and instantaneous zoom and digital “gobo” changes, making these fixtures an awesomely punchy complementary effect for all genres, venues and performances.

And with an easy-to-understand large LCD live diagnostic readout and field-serviceable alignment, the Triton series unites reliability and laser effects like never before. Built road-ready, the Triton T-2 and Triton T-5 ship individually in standard plastic Pelican-style cases and can also easily fit up to 4 units in a standard-size wheeled touring cart.

Satisfy stagehands, delight designers and amaze audiences with the Triton T-2 and T-5 from X-Laser.

Specifications:

• Source

• 2W Balanced RGB Laser Engine Direct-Injection Diode Modules

• Red: 638 nm

• Green: 520 nm

• Blue: 445 nm

• 500mW red

• 700mW green

• 800mW blue

• Photometrics/Optics

• High-Speed Closed-Loop Galvanometers,

• Max Scan Angle 45º

• 30,000 PPS Scanner Speed at 8º Scan Angle

• Beam Divergence: <1.4 mRad

• Fully Sealed Optical Deck for IP64 Usage

• Electrical/Thermal

• AC 100-240V - 50/60hZ 200W

• Neutrik PowerCON

• 0º F to 115º F (-17º C to 46º C)

• 120 cfm Cooling Fans

• Control and Interface

• X-Laser Mercury Integrated, 2.25” LCD w/ panel

• Up to 8 Layers of Basic Builder Control

• Profiles for all major console brands

• EtherStop Combined Remote Stop

• Control Data in / thru

• PowerCON in / thru

• Color and Effects

• Additive RGB Analog Color Mixing

• 1,000+ Colors

• 50 Color Macros

• 11 Digital Prisms

• 450+ “Gobos” / Digital Patterns Built-In

• 60 Motion Macros with variable speed and amplitude

• Dimensions/Physical/Materials

• 13” x 6.25” x 5” (330 mm x 159 mm x 127 mm)

• weighs ~20 lbs (~9 kg)

• IP Rating

• IP64 in both orientations (fans up / handle up)

• Other

• FDA / IEC Hazard Class IV

• U.S. FDA Variance Required
