POE Switch

The Visual Productions POESwitch is a 4-port PoE network switch with 1Gbps uplink, designed to partner with VP's lighting controllers in small to medium sized control systems.

From the Manufacturer:

The PoeSwitch is a unmanaged network switch with 4 Power-over-Ethernet ports. It's the perfect companion for connecting and powering Visual Productions lighting controllers in a small to medium size lighting control system.

The switch requires no configuration and therefore guarantees fast and seamless integration into the network. Additionally, the switch's fan-less design ensures silent operation, making this device the perfect solution for office environments.

PoE

Transfer data and power on one single cable via four PoE ports. Supports PoE power up to 15.4W for each PoE port and a total PoE budget of 60W.

DIN rail

The installation-friendly form factor ensures a fluent integration in DIN rail based electrical cabinets.

Specifications:

• DIN rail mounting
• Unmanaged network switch
• Plug&play, no configuration required
• 4x 10/100 Mbps PoE ports
• 1x 1 Gbps uplink port
• IPv4/IPv6 QoS (Quality of Service)
• IEEE 802.3af compliant PD
• 60W PoE budget, 15,4W per port
• 48V DC 60W max. (PSU optional)
• Operating temperature -20°C to +50°C (-4°F to 122°F)
• Operating relative humidity 10% to 80% non-condensing
• CE, RoHS, UKCA Compliance
