White CV Tape 24V 10M

The ENTTEC White Constant Voltage LED Strip (NA1) is a high-output, non-addressable 24V single-white LED strip available in 3000K, 4000K, and 6000K color temperatures for professional commercial, retail, hospitality, and high-output architectural installations.

Packaging Options

All variants are sold as 10-meter rolls. Select the color temperature that best suits your project:

• 3000K Warm White (SKU: CV-WHITE3K-NA1): 1,297 lm/m — soft, inviting ambience ideal for hospitality and residential applications
• 4000K Neutral White (SKU: CV-WHITE4K-NA1): 1,445 lm/m — perfect balance for commercial and workspace environments
• 6000K Cool White (SKU: CV-WHITE6K-NA1): 1,436 lm/m — bright, crisp light for commercial spaces and long runs

From the Manufacturer

ENTTEC designs and manufactures a complete range of high-quality LED strips to suit any desired mood or effect. The NA1 white CV strip delivers high output with 120 SMD2835 LEDs per meter built on a robust 4oz copper substrate for superior durability and performance. With CRI > 90, R9 > 50, and SDCM < 3, it delivers specification-grade color quality and true-to-life color reproduction — especially valuable for hospitality, retail, galleries, and high-end commercial projects requiring consistent, flattering illumination.

Unlike standard 1oz–2oz LED strips, the NA1's heavy-duty 4oz copper FPC provides higher current-carrying capacity, reduced voltage drop over long distances, better thermal regulation, improved LED longevity, and greater mechanical strength and bending reliability. The NA1 offers run lengths of up to 13m with dual injection and 10m with single injection. The strip can be cut every 50mm (6 LEDs) and features easy solder-tab connections and 3M adhesive backing for flexible installation.

Features

• Available in 3000K (warm white), 4000K (neutral white), and 6000K (cool white) — choose the color temperature to suit your project
• High output: 1,297–1,445 lm/m depending on CCT
• 120 SMD2835 LEDs per meter for high-density, uniform illumination
• Exceptional color accuracy: CRI > 90, R9 > 50, SDCM < 3
• 4oz copper FPC substrate — higher current capacity, reduced voltage drop, better thermal regulation, and greater mechanical durability vs. standard 1oz–2oz strips
• Up to 13m run length with dual injection; up to 10m with single injection
• Cuttable every 50mm (6 LEDs per cutting unit) for flexible installation layouts
• Easy solder-tab connections with 3M adhesive backing
• White PCB finish
• Compatible with ENTTEC CVC4 constant-voltage dimmer for smooth, flicker-free dimming and precise brightness control
• LED lifetime L70: >36,000 hours
• UL Listed; also compliant with FCC, UKCA, CE/WEEE, and RCM standards
• Recommended use: Commercial spaces, retail, hospitality, high-output architectural applications

Specifications

Light Source

• LED Type: SMD2835
• LED Color (CCT): Warm White (3000K) / Neutral White (4000K) / Cool White (6000K)
• LED/Meter: 120 LEDs/m
• Beam Angle: 120°
• Lumens/Meter: 1,297 lm/m (3000K) / 1,445 lm/m (4000K) / 1,436 lm/m (6000K)
• Efficacy: 88.6 lm/W (3000K) / 98.7 lm/W (4000K) / 98.09 lm/W (6000K)
• CRI: > 90
• R9: > 50
• SDCM: < 3
• LED Lifetime L70: >36,000 hours

Electrical

• Input Voltage: 24V
• Power/Meter: 14.64W/m
• Dimming Method: LED dimmable by ENTTEC CVC4 (73926)
• Connectors: 2-pin solder tabs

Physical

• PCB Color: White
• PCB Width: 10mm / 0.39"
• Spacing Between Cuttable Sections: 50mm / 1.97"
• LEDs per Cutting Unit: 6 LEDs
• Min. Bend Radius: 30mm / 1.18"
• IP Rating: IP20
• Working Temperature: -30°C to 55°C
• Storage Temperature: 0°C to 60°C
• Operating Humidity: 5–95% (non-condensing)

Shipping

• Shipping Weight (10m roll): 0.25 kg / 0.55 lbs
• Shipping Dimensions (single roll): 250 x 255 x 30mm / 9.84 x 10.04 x 1.18"

Compliance & Warranty

• Compliance: UL / RCM (Aus/NZ), CE / WEEE (EU), UKCA (UK), FCC (USA)
• Warranty: 1-year return to base manufacturer warranty
